Product Overview
- Suspension/Mount: Top running double girder design ensures stability and efficient load handling.
- Capacity: It boasts a robust lifting capacity of 3.30 tons, suitable for a variety of industrial applications.
- Reeving/Lift: Features a 2-part reeving system with a lift height of 59 feet and 5 inches, offering versatility in vertical movement.
- Hoist Lift Speed: Equipped with a maximum hoist lift speed of 26.00 feet per minute (FPM), enabling swift and efficient vertical transportation of loads.
- Hoist Motor: Powered by a reliable 7.5 kW motor, ensuring consistent and powerful lifting performance.
- Hoist Control: Utilizes closed-loop vector Variable Frequency Drive (VFD) control for precise and responsive hoist operation.
- Trolley Speed: Capable of achieving a maximum trolley speed of 80.00 FPM, facilitating quick and smooth horizontal movement of loads.
- Trolley Motor: Features two 0.55 kW motors for trolley movement, ensuring efficient load transportation across the beam.
- Trolley Control: Employs sensorless vector VFD control for accurate and responsive trolley positioning.
- Power Supply: Operates on an electric power supply rated at 230VAC, 3-phase, and 60Hz, with a tolerance of ±5%, ensuring consistent power delivery for uninterrupted operation.
- CMAA Class/Atmosphere/Location: Compliant with CMAA standards and suitable for use in Class D atmospheric conditions, offering reliability in various industrial environments.
- Trolley Gauge: Provides a trolley gauge of 66.0000 inches, allowing ample space for load clearance and maneuverability.
- Approximate Weight: Weighs approximately 2200.00 lbs, facilitating easier installation and maintenance.
Model DB7T59-26
Suspension / Mount Top Running Double Girder
Capacity 3.30 Ton
Reeving | Lift 2 PD | 59'5"
Hoist Lift Speed 26.00 FPM Max
Hoist Motor 7.5 kW
Hoist Control Closedloop vector VFD control
Trolley Speed 80.00 FPM Max
Trolley Motor 2 @ .55 kw
Trolley Control Sensorless vector VFD control
Power Supply Electric | 230VAC3PH60HZ +5%
CMAA Class | Atmosphere | Location Class D | Standard | Weather Resistant
Trolley Gauge 66.0000"
Approximate Weight: 2200.00 lbs
MODEL FEATURES
4pole, AC squirrel cage, inverter-rated hoist motor with brake.
True vertical lift and dual 4pole, AC squirrel cage inverter-rated trolley motors.
Rubber bumpers and drop lugs/rail sweeps.
Premium grade graphite ductile iron wheels and sheaves for durability.
UL508A c UL us listed industrial control panel with CSA Type 4, 4X enclosure.
Hoist closed loop flux vector drive with motor & brake proving and load floating at 0 Hz.
Hoist 0 hz speed control for precise positioning and stopping without motor brake fatigue.
Hoist 100% dynamic braking with resistor or regenerative converter.
Hoist overweight protection through frequency drive with 3% accuracy.
Trolley open loop frequency drive with dynamic braking.
Motor overload protection through frequency drives.
Adjustable upper and lower electronic encoder limits and secondary upper limit.
110 VAC control voltage (optional 24 VDC pushbutton control voltage).
90 Hz hoist speed up to 30% of rated load enable by request.
