UNDER RUNNING DOUBLE GIRDER

The Under Running Double Girder crane series represents engineering excellence and reliable performance in heavy-duty lifting applications. Designed for maximum efficiency, these cranes are equipped with advanced Variable Frequency Drive (VFD) controls for both hoisting and trolley movements, ensuring precise lifting and horizontal transport of materials in varied industrial settings. Our Under Running Double Girder products offer capacities ranging from 5.50 tons to an impressive 20 tons, catering to a wide spectrum of operational demands. With hoist lift speeds of up to 26 FPM maximum and a consistent trolley speed of 80 FPM maximum, these cranes are perfectly suited for fast-paced environments where time and productivity matter. Powering these robust systems is a reliable 230VAC-3PH-60HZ supply, allowing seamless integration into existing infrastructure. Options for trolley gauges extend from 84 inches to 108 inches, providing versatility in accommodating diverse workspace layouts. Built by Detroit, a trusted name in crane manufacturing, the Under Running Double Girder series guarantees durability and safety without compromising performance. Key models include the DB11U41-26, DB22U20-13, DB33U20-13, and the DB40U22-12, each engineered for specific load requirements while maintaining stringent safety standards. Ideal for manufacturing plants, warehouses, and construction sites, these cranes not only enhance operational efficiency but also significantly reduce downtime during material handling. Investing in continuous advancement, the Under Running Double Girder series embodies a breakthrough in lifting technology, ensuring your operational needs are met with preeminent reliability and sophistication. Explore our comprehensive range of Under Running Double Girder cranes and experience the pinnacle of industrial lifting solutions.
Sidebar Sidebar Sidebar
Compare (0)

Under Running Double Girder Cranes

Under running double girder cranes are an ideal material handling solution for facilities that require maximum hook approach, efficient load distribution, and precision movement within limited headroom environments. Mounted below the runway beams, these cranes allow for seamless integration in spaces where top-running configurations may not be practical.

Key Features & Benefits:
• Dual Girder Strength: Featuring two support girders, these cranes offer enhanced lifting capacity, extended spans, and greater load stability compared to single girder systems.
• Underslung Configuration: Operates beneath the runway structure, making it perfect for facilities with tight overhead clearance or architectural restrictions.
• Smooth Load Travel: Designed for precise, low-vibration movement, under running cranes allow for accurate load positioning along monorails or enclosed track systems.
• Flexible Installation: Can be mounted to existing building structures, reducing the need for separate support columns and allowing for more floor space.
• Increased Hook Coverage: Offers maximum end approach to efficiently cover more of the shop floor, increasing usable workspace.
• Customizable Options: Available with motorized or manual trolleys, radio remote controls, variable speed drives (VFDs), and advanced safety features to meet specific application requirements.

Common Applications:
Under running double girder cranes are used in manufacturing plants, machine shops, maintenance facilities, cleanrooms, and light to medium-duty production lines, where space-saving designs and accurate load handling are critical.

When your facility demands an efficient, low-profile overhead lifting system, under running double girder cranes deliver reliable performance, operational flexibility, and excellent load distribution—all without sacrificing valuable headroom or floor space.

!
