UNDER RUNNING DOUBLE GIRDER, Capacity: 16.50 Ton, Hoist Lift Speed: 13.00 FPM Max, Hoist Control: VFD, Trolley Speed: 80.00 FPM Max, Trolley Control: VFD, Power Supply: 230VAC-3PH-60HZ, Trolley Gauge: 96.0000, DB33U29­-13, DETROIT

Product Overview

Model DB33U29­-13
Suspension / Mount Under Running Double Girder
Capacity 16.50 Ton
Reeving | Lift 4 PD | 29'­1"
Hoist Lift Speed 13.00 FPM Max
Hoist Motor 10.4 KW
Hoist Control Closed­loop vector VFD control
Trolley Speed 80.00 FPM Max
Trolley Motor 4 @ .3 KW
Trolley Control Sensorless vector VFD control
Power Supply Electric | 230VAC­3PH­60HZ +­5%
CMAA Class | Atmosphere | Location Class D | Standard | Indoor Service
Trolley Gauge 96.0000"
Beam Size Reference Mechanical Drawing
Approximate Weight 3400.00 lbs

Type: Hanging out with the DB33U29-13! It's an under-running double girder crane, perfect for getting those heavy jobs done with ease.

Capacity: This bad boy can handle up to 16.50 tons of weight. That's like moving a whole bunch of elephants around!

Reeving | Lift: With a lifting height of 29 feet and 1 inch and a 4-part reeving system, you can hoist stuff up high and get the job done efficiently.

Hoist Lift Speed: Need to get things moving quickly? No worries! The hoist lift speed of 13.00 feet per minute ensures you can lift and lower loads with ease.

Hoist Motor: Powered by a 10.4 kW motor, this crane packs a punch when it comes to lifting power. It's like having your very own superhero to handle those heavy loads.

Hoist Control: Thanks to its closed-loop vector Variable Frequency Drive (VFD) control, you've got precise control over lifting operations. Smooth and steady wins the race!

Trolley Speed: Zooming around at a max speed of 80.00 feet per minute, the trolley makes moving loads a breeze. Get things where they need to go in no time.

Trolley Motor: With four motors each rated at 0.3 kW, the trolley's got the muscle to move your stuff around without breaking a sweat.

Trolley Control: The trolley's got some smarts too, with sensorless vector VFD control ensuring smooth and efficient movement.

Power Supply: It runs on electric power, so just plug it into your standard 230VAC, 3-phase, 60Hz outlet, and you're good to go!

CMAA Class | Atmosphere | Location Class: Built tough for indoor service in atmosphere class D conditions. This crane is ready to tackle whatever you throw at it.

Trolley Gauge: With a trolley gauge of 96.0000 inches, you've got plenty of room to maneuver and get things done.

Beam Size Reference: Check out the mechanical drawing for all the details on beam size, making sure everything fits just right.

Approximate Weight: Weighing in at around 3400.00 lbs, it's sturdy and dependable, ready to handle whatever you need to lift.
