Tractel Griphoist / Tirfor TU32H Hydraulic Wire Rope Hoist – 14,080 lb. Capacity

Product Description

The Tractel Griphoist / Tirfor TU32H Hydraulic Wire Rope Hoist is engineered for the heaviest lifting and pulling applications, delivering a nominal capacity of 6,400 kg (14,080 lbs). This hydraulic-powered model offers the strength and durability necessary for large-scale projects, while maintaining the proven reliability of Tractel’s Griphoist/Tirfor technology.

Built with a pass-through wire rope system, the TU32H allows for virtually unlimited lifting and pulling distances, making it ideal for long-haul tensioning, structural positioning, and load movement in any direction—horizontal, vertical, or at an angle. The dual jaw gripping mechanism ensures safe and consistent load holding, automatically securing the rope at every pause.

The hydraulic drive system reduces strain on the operator and increases productivity. This provides users with smooth and controlled rope travel for efficient operation. Utilizing overload protection provides an additional layer of safety, safeguarding both equipment and personnel in demanding work environments.

With its high capacity, rugged design, and versatile functionality, the TU32H Hydraulic Griphoist stands as a dependable solution for professionals handling the most challenging lifting and pulling operations.

Key Specifications

• Model: TU32H
• Part Number: 016499003-C
• Type: Hydraulic Griphoist / Tirfor Wire Rope Hoist – Complete Kit
• Nominal Capacity: 14,080 lbs (6,400 kg)
• Wire Rope Size: 5/8 in (16 mm)
• Operation Modes: Horizontal, vertical, or angled lifting and pulling
• Rope Design: Pass-through system (virtually unlimited rope length)
• Load Holding: Dual jaw gripping system with automatic locking at every stop
• Power Source: Hydraulic motor drive
• Overload Protection: Built-in shear pins and hydraulic relief safeguards
• Safety Factor: 4:1 (material handling applications)
• Applications: Heavy construction, utilities, infrastructure projects, industrial rigging, rescue operations
• Compliance: Meets ASME B30.21 standards
