Tractel Griphoist / Tirfor TU28H Hydraulic Wire Rope Hoist – 7,040 lb. Capacity

Product Description

The Tractel Griphoist / Tirfor TU28H Hydraulic Wire Rope Hoist provides its users with powerful performance with a nominal lifting and pulling capacity of 7,040 lbs. (3,200 kg). Designed for demanding industrial and utility applications, this hydraulic model combines the proven reliability of the Griphoist system with the efficiency of a motorized drive, making it an ideal solution when manual operation is not practical.

Using Tractel’s pass-through wire rope design, the TU28H allows for virtually unlimited lifting or pulling distances. The dual jaw gripping system ensures constant load holding and automatic locking during pauses, providing unmatched safety and control in every operation.

Hydraulic power eliminates operator fatigue while providing smooth and steady rope travel, improving efficiency in applications such as construction lifting, structural positioning, line pulling, and rescue operations. Built-in overload protection safeguards both the hoist and operator, while the compact and rugged design makes it easy to transport and set up in the field.

With its combination of high capacity, efficiency, and reliability, the TU28H Hydraulic Griphoist is the go-to choice for professionals who need heavy-duty lifting and pulling capability with maximum safety and versatility.

Key Specifications

• Model: TU28H
• Type: Hydraulic Griphoist / Tirfor Wire Rope Hoist
• Nominal Capacity: 7,040 lbs (3,200 kg)
• Wire Rope Diameter: 7/16 in (11.5 mm)
• Rope Travel (Forward): ~2.95 ft/min (0.9 m/min)
• Rope Travel (Reverse): ~5.9 ft/min (1.8 m/min)
• Operation Modes: Horizontal, vertical, or angled pulling and lifting
• Rope Design: Pass-through system (virtually unlimited rope length)
• Load Holding: Dual jaw gripping system with automatic rope lock at every stop
• Power Source: Hydraulic motor drive
• Overload Protection: Shear pin system with hydraulic relief safeguards
• Safety Factor: 4:1 (material handling applications)
• Applications: Heavy construction, utilities, industrial rigging, rescue, infrastructure projects
• Compliance: Meets ASME B30.21 standards
