Standard Fold-Away Anchor TrackTM System 1-User (Non-Passable) Trussed Single Track, includes (2) Support Arms, Arm Reach: 10'-0", Bracket Centers 5'-0", Thrust/Pull Loading: ± 4500, Weight: 1201 lbs FAF-1-10-33-530-30 Rigid Lifelines

Product Overview

Worker Capacity: The Fold-Away Anchor TrackTM System is designed to accommodate a single user, ensuring a non-passable configuration for enhanced safety in industrial environments.

Trussed Single Track Design: This system features a robust trussed single track design, providing optimal structural integrity while minimizing weight for efficient handling and installation.

Support Arms: Equipped with two support arms, the system offers enhanced stability and load-bearing capacity, ensuring reliable performance in various working conditions.

Arm Reach: With an arm reach of 10 feet, users can effectively access distant areas within the workspace, facilitating versatile operations and task completion.

Track Length: The track spans 33 feet in total length, including 18-inch overhangs on both ends, providing ample coverage and accessibility throughout the designated work area.

Optimal Support and Bracket Centers: Supported by brackets spaced 30 feet apart and with bracket centers at 5-foot intervals, the system ensures optimal support distribution and structural stability for safe operation.

Rotation Lock Feature: One of the support arms is equipped with a rotation lock mechanism, allowing for controlled movement and preventing unintended rotation, thereby enhancing safety during use.

Customizable Drop Length of Operating Rope: Customers have the option to specify the drop length of the operating rope, ensuring tailored installation and operation according to specific requirements.

Anchor Trolley with Patented Auto-Brake Technology: The system includes an anchor trolley featuring patented auto-brake technology, ensuring smooth and controlled movement along the track while enhancing safety by preventing unintended traversal.

Fixed Stops: Fixed stops are installed at each end of the track, serving as safety measures to prevent the trolley from traversing beyond the designated limits, thereby ensuring safe and controlled operation.

High Thrust/Pull Loading Capacity: Capable of withstanding thrust or pull loading of up to ±4500 pounds, the system demonstrates exceptional strength and durability, making it suitable for demanding industrial applications.

Optimized Weight: Weighing approximately 1201 pounds, the system strikes a balance between structural stability and maneuverability, facilitating ease of installation and adjustment while ensuring reliable performance.

Durable Coating and Painting: Coated with yellow industrial enamel designed for indoor applications, the system offers superior corrosion resistance and durability, maintaining a professional appearance in indoor work environments.

Comprehensive System Inclusions: The system comes complete with swing arms, track, trolley(s), end stops, splice(s) (if applicable), and hangers, providing all necessary components for seamless installation and operation.

Fold-Away Anchor TrackTM System Standard
Worker Capacity: 1-User (Non-Passable) Trussed Single Track
Includes (2) Support Arms
Arm Reach: 10'-0"
Track Length: 33-0" Including 18" Overhangs on Both Ends
Support Centers 30-0"
Bracket Centers 5'-0"
Rotation Lock on One Arm Included
*Customer Must Specify Drop Length of Operating Rope - ONLY IF MANUAL,
REMOVE IF MOTORIZED*
**Designed to be used ONLY when fully extended**
Trolleys: 1 Anchor Trolley(s) with Patented Auto-Brake
Technology
Fixed Stops aOne at Each End
Thrust/Pull Loading: ± 4500
Weight: ± 1201 lbs
Coating & Painting: Yellow Industrial Enamel for Indoor Application
The system is complete with swing arms, track, trolley(s), end stops, splice(s) (if
applicable), and hangers.
