Standard Fold-Away Anchor TrackTM System 1-User (Non-Passable) Trussed Single Track, includes (2) Support Arms, Arm Reach: 10'-0", Bracket Centers 5'-0", Thrust/Pull Loading: ¬± 4500, Weight: 1079 lbs FAF-1-10-28-525-25 Rigid Lifelines

RIGID LIFELINES

MSRP: $10,670.00

$8,802.75

(You save $1,867.25 )

(No reviews yet) Write a Review

SKU:: FAF-1-10-28-525-25
Weight:: 1,079.00 LBS
Shipping:: Calculated at Checkout

Overview
Product Videos
Reviews

Product Overview

Worker Capacity: Designed for a single user, the Fold-Away Anchor TrackTM System ensures non-passable functionality, prioritizing safety in industrial environments.

Trussed Single Track Design: The system features a trussed single track design, providing robust support and stability while minimizing weight for efficient operation.

Support Arms: Equipped with two support arms, the system offers enhanced stability and structural reinforcement, ensuring safe and reliable performance.

Arm Reach: With an arm reach of 10 feet, users can access distant points within the workspace efficiently, facilitating versatile operations and task completion.

Track Length: The track spans 28 feet in length, including 18-inch overhangs on both ends, providing comprehensive coverage and accessibility within the workspace.

Optimal Support and Bracket Centers: Supported by brackets spaced 25 feet apart and with bracket centers at 5 feet intervals, the system ensures optimal support and stability during operation, enhancing safety and performance.

Rotation Lock Feature: One of the support arms is equipped with a rotation lock mechanism, providing controlled movement and preventing unintended rotation for enhanced safety.

Customizable Drop Length of Operating Rope: Customers have the option to specify the drop length of the operating rope, allowing for tailored installation and operation based on individual requirements.

Anchor Trolley with Patented Auto-Brake Technology: The system includes an anchor trolley featuring patented auto-brake technology, ensuring smooth and controlled movement along the track while enhancing safety and preventing unintended traversal.

Fixed Stops: Fixed stops are installed at each end of the track, preventing the trolley from traversing beyond the designated limits and enhancing safety during operation.

High Thrust/Pull Loading Capacity: Capable of withstanding thrust or pull loading of up to ±4500 pounds, the system demonstrates exceptional strength and durability for demanding industrial environments.

Optimized Weight: Weighing approximately 1079 pounds, the system strikes a balance between structural stability and maneuverability, facilitating ease of installation and adjustment.

Durable Coating and Painting: Coated with yellow industrial enamel suitable for indoor applications, the system offers superior corrosion resistance and durability, maintaining a professional appearance in indoor work environments.

Comprehensive System Inclusions: The system is complete with swing arms, track, trolley(s), end stops, splice(s) (if applicable), and hangers, providing all necessary components for seamless installation and operation.

Fold-Away Anchor TrackTM System Standard
Worker Capacity: 1-User (Non-Passable) Trussed Single Track
Includes (2) Support Arms
Arm Reach: 10'-0"
Track Length: 28'-0" Including 18" Overhangs on Both Ends
Support Centers 25'-0"
Bracket Centers 5'-0"
Rotation Lock on One Arm Included
*Customer Must Specify Drop Length of Operating Rope - ONLY IF MANUAL,
REMOVE IF MOTORIZED*
**Designed to be used ONLY when fully extended**
Trolleys: 1 Anchor Trolley(s) with Patented Auto-Brake
Technology
Fixed Stops One at Each End
Thrust/Pull Loading: ± 4500
Weight: ± 1079 lbs
Coating & Painting: Yellow Industrial Enamel for Indoor Application
The system is complete with swing arms, track, trolley(s), end stops, splice(s) (if
applicable), and hangers.
