Product Overview
Duct-O-Wire L4-S-1 Pendant Push Button Station
General Description:
The Duct-O-Wire L4-S-1 Pendant Push Button Station is a compact and robust control unit from the L Series, engineered for simple, momentary operation in a wide range of industrial environments. It features a single On/Off button in a slim, ergonomic housing, the L4-S-1 offers a user-friendly interface for hoist, crane, or machinery control.
Technical Specifications:
CategorySpecification
Model Number L4-S-1
Series L Series
Switch Type 1-Button, Momentary On/Off
Housing Material High-impact Polypropylene
Profile Type Slim Back (S)
Cable Entry Multi-Step Cord Grip (Supports 4 to 24 conductor cables)
Environmental Ratings NEMA 1, 3, 4, 4X, 12
CSA Certification CSA Approved – Certification #150928
Standards Tested to CSA and UL standards
Ingress Protection (IP) Equivalent to NEMA 4/4X when no cord grip is installed
Boots Replaceable Neoprene Boots
Legend Plates Easy-to-read plates for clear labeling
Strain Relief Includes Hook and Cable Clamp Set
Accessory Switches Not included in this model (basic On/Off functionality)
Wiring Space Options Optional Deep Back (D) Profile available
Applications Hoists, Cranes, Conveyor Systems, Industrial Equipment
Features:
- Single-button momentary control for simple operations
- Durable polypropylene housing resists impact and harsh conditions
- Slim profile for ergonomic handling
- Field-serviceable components, including replaceable boots
- Fully sealed design rated for indoor and outdoor use
- CSA approved and built to UL standards
