Product Overview
Duct-O-Wire L6-S-2M Pendant Push Button Station
The Duct-O-Wire L6-S-2M from the L Series is a compact, rugged pendant push button station engineered for precise and reliable control of industrial machinery. Designed with a two-motion configuration, it features two push buttons that provide direct, separate control over two distinct machine functions—ideal for applications such as hoists, cranes, and conveyors.
With a slim back profile and ergonomic polypropylene housing, the L6-S-2M is built to withstand the rigors of demanding environments. It meets NEMA 1, 3, 4, 4X, and 12 standards for protection against dust, water, and corrosion, making it the perfect fit for both indoor and outdoor use.
Installation is quick and flexible thanks to its lightweight build, multi-step cord grip, and cable clamp set. The device also includes replaceable neoprene boots and easy-to-read legend plates, ensuring long-lasting usability and simple operation.
Key Features and Specifications:
- Enclosure Type: 6 Button Shallow (configured for 2 motions)
- Dimensions:
- Width: 3.13 in.
- Depth: 2.00 in.
- Length: 10.50 in.
- Cable Range: 0.640 to 0.890 in.
- Shipping Weight: Approx. 0.74 lbs.
- Material: Durable polypropylene construction
- Environmental Ratings: NEMA 1, 3, 4, 4X, and 12
- Cord Grip: Multi-step for 4 to 24 conductor cable
- Additional Components: Strain relief hook and cable clamp set
- Boots: Replaceable neoprene
- Certifications: UL Listed and CSA Approved
- Accessories: Compatible with a series of optional switches and accessories
