Product Overview
The Duct-O-Wire L6-S-2 Pendant Push Button Station represents a compact, robust, and ergonomically engineered control solution, particularly well-suited for industrial applications, including overhead cranes, hoists, and conveyors. As a component of the reputable L Series, this two-button pendant station provides precise two-motion control, establishing itself as a dependable interface for machinery operation.
Constructed from high-quality polypropylene, the L6-S-2 is designed to withstand the harsh industrial environments, including exposure to moisture, chemicals, and extreme temperatures. Its slim, sleek design enhances both comfort and functionality, while the durable construction ensures longevity and consistent performance.
With versatility as a key consideration, this station features a multi-step cord grip that accommodates a variety of cable sizes and conductor configurations. The L6-S-2 is both UL-listed and CSA-approved, boasting NEMA-rated enclosures that comply with stringent safety and environmental standards.
Whether installed on cranes, hoists, or other automated systems, the Duct-O-Wire L6-S-2 provides operators with accurate, responsive control in a compact and easy-to-install package.
Technical Specifications:
FeatureDetails
Model Number L6-S-2
Series Duct-O-Wire L Series
Enclosure Type 6 Button Shallow (2-Button Configured)
Dimensions 10.50 in. (L) × 3.13 in. (W) × 2.00 in. (D)
Cable Range 0.640 to 0.890 in.
Shipping Weight Approximately 0.74 lbs.
Housing Material Polypropylene
Environmental Ratings NEMA 1, 3, 4, 4X, and 12
Cord Grip Multi-step for 4 to 24 conductor cable
Boots Replaceable Neoprene
Mounting Includes Strain Relief Hook and Cable Clamp Set
Control Type Two-Motion (Up/Down, Forward/Reverse, etc.)
Approvals UL Listed, CSA Approved
Additional Features : Easy-to-read legend plates; ergonomic design
Accessories A Large variety of accessory switches are available
