Atlas Lifting & Rigging 1 Ton Low Headroom Beam Trolley with 20 ft Chain

Product Overview

Atlas Lifting & Rigging ALBT-010-20

1 Ton Low Headroom Beam Trolley with 20 ft Chain

The Atlas ALBT-010-20 is a 1-ton, low-headroom beam trolley designed for maximum lifting efficiency in areas with vertical clearance restrictions. This integrated trolley-hoist unit delivers both lifting and horizontal travel within a compact, combined profile—ideal for applications where space is limited and lifting height is critical.

Built with precision-machined components, heavy-duty steel construction, and a reliable hand chain mechanism, the ALBT-010-20 ensures smooth operation and dependable load handling. With a 20-foot lift height and integrated trolley wheels, it is ready for demanding jobs in warehouses, maintenance facilities, and tight overhead rigging systems.

Key Features:

• Low Headroom Design: Compact build maximizes vertical lift in tight spaces
• 1 Ton Capacity: Rated for up to 2,200 lbs
• Integrated Manual Chain Hoist & Trolley: Streamlined setup for ease of use and reduced installation time
• 20 ft Lift Height: Generous chain length for a versatile lifting range
• Push Trolley Wheels: Smooth manual movement along I-beam tracks
• All-Steel Construction: Built for industrial durability and long-term use
• Sealed Bearings & Machined Gearing: Low-maintenance and efficient operation
• Ideal for Tight Clearances: Common in utility rooms, service bays, and low-ceiling environments

Technical Specifications:

SpecificationDetails

Model Number ALBT-010-20

Rated Capacity 1 Ton (2,200 lbs)

Lift Height 20 ft

Headroom Clearance Low profile (varies by beam flange)

Trolley Type Manual Push Type

Trolley Adjustment Adjustable for standard I-beam widths

Chain Type Hand Chain – Manual Operation

Construction High-Strength Steel

Bearing Type Sealed Ball Bearings

Net Weight Approx. 75–90 lbs

Compliance ASME B30.16 / B30.11, CE Certified
