Product Overview
Atlas Lifting and Rigging APT-010 Push Beam Trolley – 1 Ton Capacity
The APT-010 Push Trolley offers reliable and efficient load handling for your overhead lifting setup. Designed to carry 1 ton (2,000 lbs), this push-type beam trolley enables easy, manual movement of hoists or loads along a wide range of I-beams or H-beams.
Built for industry with heavy-duty steel construction, precision-machined wheels, and sealed ball bearings. This trolley ensures smooth operation and long-term durability. Perfect for workshops, factories, and construction sites. This trolley installs quickly and safely, making it a dependable choice for suspended load mobility.
Key Features:
- 1-Ton Load Capacity: Built for medium-duty lifting and transport applications.
- Smooth Push Travel: Easy manual movement along the beam with minimal resistance.
- Adjustable Flange Width: Fits a wide variety of beam sizes.
- Sealed Ball Bearings: Ensure smooth rolling and maintenance-free operation.
- All-Steel Construction: Durable side plates and robust components for heavy use.
- Anti-Drop Safety Plates: Help secure the trolley on the beam for added protection.
- Low Headroom Profile: Maximizes vertical lift space, ideal for tight clearances.
Specifications:
- Model: APT-010
- Capacity: 1 Ton (2,000 lbs / 907 kg)
- Beam Width Range: Approx. 2.5" to 8" (adjustable)
- Wheel Type: Steel wheels with sealed ball bearings
- Body Construction: Powder-coated steel frame
- Suspension Type: Central eye for hook-mounted hoists
- Net Weight: Approx. 24 lbs (10.9 kg)
The Atlas APT-010 offers a rugged and easy-to-use solution for hoist mobility and load transportation across overhead beams. Fast to install and built to perform—perfect for any facility where reliability and safety matter.
