Atlas Lifting and Rigging ALH-008-05 Manual Lever Hoist

The ALH-008-05 is a compact and durable manual lever hoist designed for precise lifting, pulling, and tensioning applications with a capacity of 0.8 tons (1,600 lbs) and a 5-foot lift height. This versatile lever hoist provides smooth, reliable operation and is ideal for tight spaces or jobs that require controlled, incremental lifting.

Its rugged steel frame, heat-treated alloy steel load chain, and internal gearing give you dependable performance and longevity. The lever mechanism features a comfortable grip for simple operation and quick load direction changes with a simple switch.

Key Features:

• 0.8-Ton Lifting Capacity: Ideal for light-duty lifting, pulling, and tensioning tasks.
• 5-Foot Lift Height: Compact lift range suitable for confined spaces.
• Heavy-Duty Steel Construction: Durable frame designed for harsh environments.
• Heat-Treated Alloy Steel Load Chain: Strong and wear-resistant chain for safety and longevity.
• Ergonomic Lever Handle: Provides comfortable and controlled operation.
• Quick-Change Load Direction: Simple lever for fast switching between lifting and lowering.
• Forged Steel Hooks with Safety Latches: Secure load attachment with 360° swivel.

Specifications:

• Model: ALH-008-05
• Capacity: 0.8 Ton (1,600 lbs / 725 kg)
• Lift Height: 5 ft (1.5 m)
• Load Chain: Heat-treated alloy steel
• Lever Handle Length: Approx. 14 inches
• Hook Type: Forged steel swivel hooks with safety latches
• Operating Temperature: -40°F to 140°F (-40°C to 60°C)
• Net Weight: Approx. 15 lbs (6.8 kg)

The Atlas ALH-008-05 lever hoist provides precise control, durability, and safety for light-duty lifting and pulling operations, making it a reliable tool for a wide range of industrial and maintenance applications.
