ALR Titon Electric Chain Hoist / Single Phase / 1/2 TON / 1,100 LBS / 15 FT LIFT

Atlas Titon Electric Chain Hoist – TEH-1-005-15

1/2 Ton Capacity | 15-Foot Lift | Single Speed

The Atlas TEH-1-005-15 Titon Electric Chain Hoist is engineered for precise and dependable lifting in light- to medium-duty industrial applications. Having a lifting capacity of 1/2 ton (1,100 lbs) and an extended 15-foot lift height, this hoist offers enhanced versatility for elevated or recessed lifting requirements. Built for performance and safety, it combines a powerful motor, durable components, and smooth operation—making it ideal for manufacturing, fabrication, maintenance, and warehouse environments.

Features

• Electric-Powered Efficiency: Equipped with a single-speed motor for steady, controlled lifting of up to 1/2 ton (1,100 lbs).
• Extended 15-Foot Lift: Offers greater lifting reach for overhead applications and increased flexibility in elevated workspaces.
• High-Strength Load Chain: Utilizes Grade 80 alloy steel chain with a black oxide finish for enhanced durability and wear resistance.
• Thermally Protected Motor: Designed for continuous operation with integrated thermal overload protection to prevent overheating.
• Electromagnetic Load Brake: Provides secure load holding and instant response in the event of a power interruption.
• Compact Housing: Features a rugged, sealed aluminum enclosure to protect internal components from dust and light moisture.
• Low-Voltage Pendant Control: Supplied with a 24V control pendant for user safety and simple, reliable operation.
• Forged Hook Suspension: Top hook allows quick attachment to beam clamps, trolleys, or fixed suspension points.

Specifications

• Model: TEH-1-005-15
• Brand: Atlas Lifting & Rigging
• Rated Capacity: 1/2 Ton (1,100 lbs)
• Lift Height: 15 ft
• Lifting Speed: Single speed (approximately 16 feet per minute; confirm per motor spec)
• Load Chain: Grade 80 alloy steel, black oxide coated
• Brake System: Electromagnetic load brake
• Motor Type: Heavy-duty electric with thermal protection
• Control Voltage: 24V low-voltage push-button pendant
• Mounting Type: Top hook suspension
• Enclosure Rating: IP54 (dust and splash resistant)
• Weight: Approx. 75–82 lbs (depending on configuration)
• Duty Cycle: 30% ED (intermittent use)
• Power Supply: Standard voltage options available (confirm before installation)
• Warranty: 3-Year Limited
• Country of Origin: China

The TEH-1-005-15 is a dependable solution for extended-reach lifting tasks in controlled environments. Its combination of power, reach, and safety features makes it a wise choice for industrial operators seeking performance and efficiency in electric hoist applications.
