Product Overview
Atlas Titon Electric Chain Hoist – TEH-1-005-10
1/2 Ton Capacity | 10-Foot Lift | Single Speed
The Atlas TEH-1-005-10 Titon Electric Chain Hoist is a compact and reliable lifting solution engineered for light- to medium-duty industrial applications. With a rated capacity of 1/2 ton (1,100 lbs) and a 10-foot lift height, this electric hoist offers smooth, controlled vertical movement and efficient handling of small to mid-sized loads. Built with durable components and a robust motor, it is ideal for general manufacturing, maintenance operations, and light assembly work.
Features
- Electric Lifting Efficiency: Single-speed electric motor enables consistent and controlled lifting of up to 1/2 ton (1,100 lbs).
- 10-Foot Lift Height: A standard 10-foot lift offers sufficient range for most light-duty lifting applications.
- Grade 80 Load Chain: Fitted with a high-strength alloy steel chain treated for wear resistance and long service life.
- Heavy-Duty Motor: Thermally protected motor supports continuous operation with high reliability and reduced downtime.
- Mechanical Load Brake: An integrated electromagnetic brake ensures precise load control and holding even under power loss.
- Durable Housing: Compact and sealed cast aluminum body resists dust, debris, and moderate moisture exposure.
- Pendant Control: Comes with a low-voltage push-button pendant for safe and easy remote operation.
- Upper Hook Suspension: A forged steel suspension hook allows for secure overhead mounting.
Specifications
- Model: TEH-1-005-10
- Brand: Atlas Lifting & Rigging
- Rated Capacity: 1/2 Ton (1,100 lbs)
- Lift Height: 10 ft
- Chain Type: Grade 80 alloy steel
- Lifting Speed: Single speed (typically ~16 FPM; confirm exact speed per motor rating)
- Motor Type: Heavy-duty electric with thermal overload protection
- Brake Type: Electromagnetic load brake
- Control Voltage: 24V low-voltage pendant
- Power Supply: Standard voltage options available (confirm per application)
- Mounting Type: Hook suspension
- Weight: Approx. 68–75 lbs (varies slightly by configuration)
- Duty Cycle: Typically 30% ED (intermittent duty)
- Enclosure Rating: IP54 or equivalent (dust and splash resistant)
- Warranty: 3-Year Limited
- Country of Origin: China
The TEH-1-005-10 offers safe, efficient lifting in a compact and economical package. It is an excellent choice for workshops, production floors, and service environments where electric-powered lifting improves productivity and operator comfort.
