Tractel Top Rack Jack BT 5 – 13.6 in (345 mm) Lift - 5,000 kg Capacity

The Top Rack Jack BT 5 is a mechanical lifting jack designed for those professionals who need exceptional strength and precision when working with heavy equipment and industrial loads. With a lifting capacity of 5,000 kg (11,023 lbs) and a lift height of 345 mm (13.6 in), this rack-and-pinion jack provides reliable, safe, and controlled lifting performance for even the toughest applications.

Built for Supieor Performance

Constructed from high-grade steel, the BT 5 is built to endure demanding work environments while maintaining smooth operation under heavy loads. Its rack and pinion system gives you consistent lifting motion and durability. Designed without hydraulics, it eliminates the risk of leaks or pressure loss, offering a low-maintenance lifting solution.

Safety You Can Count On

Using a double-pawl ratchet mechanism, the BT 5 provides secure load holding during operation. A friction disc brake system allows controlled lowering, giving the operator confidence and control when working with valuable or sensitive equipment. Every lift is smooth, stable, and protected from accidental release.

Versatile and Practical Design

The folding crank handle allows for easy handling, compact storage, and fast setup. The BT 5 can lift from both the head and toe, making it adaptable for a variety of lifting scenarios — especially in tight or low-clearance spaces. It’s ideal for applications that require precise alignment or steady elevation of large, heavy machines.

Specifications

• Model / SKU: BT 5 / 196480
• Lifting Capacity: 5,000 kg (11,023 lbs)
• Lift Height (Stroke): 345 mm (13.6 in)
• Minimum Height (Lowered): ~660 mm
• Toe (Claw) Height: ~80 mm
• Weight: ~45 kg
• Crank Effort: ~45 daN (≈ 450 N)
• Mechanism: Rack-and-pinion with friction disc brake
• Construction: Heavy-duty, heat-treated steel components
• Operation: Manual crank with double safety pawl system
• Finish: Industrial-grade corrosion-resistant coating

Recommended Uses

• Lifting and positioning large industrial machinery
• Maintenance and installation of heavy production equipment
• Mechanical lifting where hydraulic systems aren’t suitable
• Industrial plants, construction sites, and machine shops

Key Advantages

• Exceptional 5,000 kg lifting capacity for heavy-duty work
• Durable all-steel construction for long service life
• Safe, controlled lifting and lowering with built-in brake system
• Compact and portable design with folding crank handle
• Operates from head or toe for versatile use in tight spaces

The Tractel Top Rack Jack BT 5 delivers unmatched lifting strength and precision in a easy-to-use design. Trusted by industrial professionals, it provides maximum control, and safety for lifting and positioning the heaviest loads with confidence.
