Tractel Top Rack Jack BT 10 – 15.3 in (390 mm) Lift - 10,000 kg Capacity

When maximum lifting strength and reliability are non-negotiable, the Top Rack Jack BT 10 delivers. Engineered for extreme industrial demands, this mechanical rack-and-pinion jack provides a powerful 10,000 kg (22,046 lbs) lifting capacity with a lift height of 390 mm (15.3 in). Designed for controlled, and safe operation, the BT 10 is the trusted choice for professionals working with heavy machinery, plant equipment, and large structural loads.

Built for Extreme Loads

The BT 10’s heavy-duty all-steel frame and heat-treated rack and pinion components provide exceptional strength and long-term durability. Every element is engineered to handle the stresses of heavy industrial use while giving you smooth, consistent performance. This mechanical design eliminates hydraulic failure risks, offering a dependable, low-maintenance lifting solution suitable for continuous professional use.

Safe, Controlled, and Stable

A double-pawl ratchet system secures the load at every step of the lift, while a friction disc brake allows precise, gradual lowering. Operators maintain full control under load, ensuring safety during positioning or installation. Even at maximum capacity, the BT 10 delivers smooth, balanced lifting with minimal operator effort.

Versatile and Practical Design

Featuring a folding crank handle for storage and easy portability, the BT 10 is designed for convenience without sacrificing performance. It can lift from either the head or the toe which makes it adaptable for a range of lifting tasks, including low-clearance situations and heavy machine alignment.

Specifications

• Model / SKU: BT 10 / 196481
• Lifting Capacity: 10,000 kg (22,046 lbs)
• Lift Height (Stroke): 390 mm (15.3 in)
• Minimum Height (Lowered): ~700 mm
• Toe (Claw) Height: ~90 mm
• Weight: ~70 kg
• Crank Effort: ~50 daN (≈ 500 N)
• Mechanism: Rack-and-pinion with friction disc brake
• Construction: Heat-treated, high-strength steel
• Operation: Manual crank with double safety pawl system
• Finish: Corrosion-resistant, industrial-grade coating

Recommended Uses

• Lifting and supporting very heavy industrial machinery
• Construction and plant maintenance applications
• Equipment positioning and alignment
• Heavy-duty installations where precision and control are critical

Key Advantages

• Massive 10,000 kg lifting capacity for the heaviest loads
• Precision rack-and-pinion system ensures smooth, stable operation
• Safe load control with double pawl and friction brake
• Built for industrial longevity and minimal maintenance
• Compact design with folding handle for portability and convenience
