Tractel Top Rack Jack BT 3 – 14 in (355 mm) Lift - 3,000 kg Capacity

The Top Rack Jack BT 3 is a powerful, precision-engineered mechanical lifting solution designed for professionals handling heavy machinery and equipment. With a lifting load capacity of 3,000 kg (6,614 lbs) and a lift height of 355 mm (14 in), this rack-and-pinion jack provides safe, controlled, and reliable lifting for industrial, workshop, and maintenance applications.

Durable, Heavy-Duty Construction

Built to withstand demanding industrial environments, the BT 3 features a robust steel frame and heat-treated pinion and rack system. This allows smooth, precise operation under heavy loads while minimizing wear and reducing the need for maintenance. The mechanical rack-and-pinion design offers consistent, repeatable lifting without hydraulic components.

Safe and Controlled Operation

The jack incorporates a double-pawl ratchet mechanism for added safety during lifting, and a friction disc brake for controlled lowering. These features allow users to handle heavy loads easily, making it ideal for installations, alignment, and equipment positioning.

Compact and Versatile

Despite its high load capacity, the BT 3 is compact and portable. Its folding crank handle allows for easy storage and transport. The jack can lift from either the head or the toe, providing flexibility in tight or restricted spaces, and making it adaptable to a wide range of industrial tasks.

Specifications

• Model / SKU: BT 3 / 196479
• Lifting Capacity: 3,000 kg (6,614 lbs)
• Lift Height (Stroke): 355 mm (14 in)
• Minimum Height (Lowered): ~640 mm
• Toe (Claw) Height: ~75 mm
• Weight: ~30 kg
• Crank Effort: ~40 daN (≈ 400 N)
• Mechanism: Rack-and-pinion with friction disc brake
• Construction: Heat-treated steel gears and frame
• Operation: Manual crank with double pawl ratchet
• Finish: Corrosion-resistant, industrial-grade coating

Recommended Uses

• Lifting and positioning heavy industrial machinery
• Equipment installation and maintenance projects
• Situations where precise, controlled lifting is required
• Industrial workshops, factories, and service facilities

Key Advantages

• Heavy-duty steel construction for strength and durability
• Smooth, controlled lifting with safety pawl and friction disc
• Lifts from head or toe for versatile use
• Compact and portable for easy handling
• Minimal maintenance required for long-term reliability
