Product Overview
Duct-O-Wire RC-3M2 Series
Industrial Radio/Remote Control System
The Duct-O-Wire RC-3M2 Series is a rugged, crystal-based industrial radio control system engineered for reliable and secure control of overhead cranes, hoists, and other industrial machinery. This 3-motion, 2-speed system offers enhanced safety, performance, and versatility for demanding environments.
With its compact, 8-pushbutton transmitter and robust receiver unit, the RC-3M2 delivers seamless operation across a 300 ft range, utilizing synchronous transmission encoding and decoding for maximum accuracy and interference resistance. The system is housed in IP65-rated fiberglass enclosures, suitable for both indoor and outdoor use.
Key Features
- 3-Motion / 2-Speed Control
- 300 ft Operational Range
- Crystal-Based Design with Secure Encoding
- Shock-Resistant Construction
- 32-bit Unique ID Code for Signal Security
- Response Time: 65ms
- IP65 Rated for Harsh Environments
- AC Power Standard; DC Options Available
- Includes: 2 Transmitters + 1 Receiver
- 2-Year Manufacturer’s Warranty
Transmitter Specifications
FeatureSpecification
Dimensions 6.4" L x 1.9" W x 1.8" H
Weight 0.6 lbs
Power Supply 2 × AA alkaline batteries
Power Consumption ~40mA
Indicators 3-stage LED power indicator
Alerts Built-in buzzer/alarm
Security 4-digit password power-on
Buttons 8 customizable pushbuttons
Design Shock-resistant, waterproof key
Receiver Specifications
FeatureSpecification
Dimensions 6.6" L x 6.1" W x 3.5" H
Weight 3.1 lbs
Input Voltage 110 VAC (Standard)
Output Relays 10A @ 250V, fused
Enclosure Fiberglass, IP65 rated
Temperature Range -30°C to +75°C
Circuit Features Alarm output, signal light output, anti-power interrupt, watchdog safety
Frequency Range 310.0325 – 321.535 MHz
Receiver Design Triple superheterodyne, frequency deviation tracking
Model Options
Model Description
RC-3M2 Standard version with separate commons
