Standard Fold-Away Anchor TrackTM System 2-User (Non-Passable) Trussed Single Track, includes (2) Support Arms, Arm Reach: 10'-0", Bracket Centers 5'-0", Thrust/Pull Loading: ± 6000, Weight: 1282 lbs FAF-2-10-33-520DST-30 Rigid Lifelines

Product Overview

• Worker Capacity: The system is designed to accommodate 2 users, emphasizing safety with its non-passable feature and utilizing a trussed single track design.
• Support Arms: Included in the system are two robust support arms, enhancing stability and load-bearing capacity during operations.
• Arm Reach: With an extended arm reach of 10 feet, the system offers expanded coverage for various operational tasks, ensuring flexibility and efficiency.
• Track Length: Spanning 33 feet, inclusive of 18-inch overhangs on both ends, the track provides comprehensive coverage while allowing for maneuverability.
• Support and Bracket Centers: Strategically positioned support and bracket centers at 30 feet and 5 feet respectively contribute to the system's stability and structural integrity.
• Rotation Lock: A rotation lock mechanism is integrated into one of the support arms, providing precise control and stability during operations.
• Operating Rope Specification: Customers have the option to specify the drop length of the operating rope, particularly relevant for manual operation, thereby customizing the system to specific requirements.
• Usage Guidelines: Emphasizing safety, the system is designed for use ONLY when fully extended, ensuring optimal performance and minimizing risks during operation.
• Anchor Trolleys with Auto-Brake Technology: Equipped with two anchor trolleys featuring patented auto-brake technology, the system ensures enhanced control and safety during movement, automatically engaging brakes to secure trolleys in position.
• Fixed Stops: Fixed stops positioned at both ends of the track provide precise endpoints for operational activities, ensuring accuracy and preventing overextension.
• Thrust/Pull Loading and Weight Capacity: Boasting a thrust/pull loading capacity of approximately ± 6000, the system is suitable for a wide range of applications while maintaining a weight of approximately ± 1282 lbs, ensuring a balance between robustness and maneuverability.
• Coating and Painting: Finished in yellow industrial enamel, the system is designed for indoor applications, offering durability and corrosion resistance.

Fold-Away Anchor TrackTM System Standard
Worker Capacity: 2 -User (Non-Passable) Trussed Single Track
Includes (2) Support Arms
Arm Reach: 10'-0"
Track Length: 33'-0" Including 18" Overhangs on Both Ends
Support Centers 30'-0"
Bracket Centers 5'-0"
Rotation Lock on One Arm Included
*Customer Must Specify Drop Length of Operating Rope - ONLY IF MANUAL,
REMOVE IF MOTORIZED*
**Designed to be used ONLY when fully extended**
Trolleys: 2 Anchor Trolley(s) with Patented Auto-Brake
Technology
Fixed Stops Two at Each End
Thrust/Pull Loading: ± 6000
Weight: ± 1282 lbs
Coating & Painting: Yellow Industrial Enamel for Indoor Application
The system is complete with swing arms, track, trolley(s), end stops, splice(s) (if
applicable), and hangers.
