Standard Fold-Away Anchor TrackTM System 2-User (Non-Passable) Trussed Single Track, includes (2) Support Arms, Arm Reach: 6'-0", Bracket Centers 4'-0", Thrust/Pull Loading: ± 4400, Weight: 1128 lbs FAF-2-06-33-520DST-30 Rigid Lifelines

Product Overview

Worker Capacity: This system is engineered to accommodate up to 2 users, ensuring compliance with safety standards by adopting a non-passable configuration on its trussed single track.

Support Arms: Included in the system are two support arms, strategically positioned to enhance stability and structural integrity during operation.

Arm Reach: With an arm reach of 6 feet, users can effectively access various points within their workspace, facilitating efficient task execution.

Track Length: The track spans a total length of 33 feet, inclusive of 18-inch overhangs on both ends, thereby providing extensive coverage for versatile applications.

Support and Bracket Centers: Supporting the track are centers spaced at intervals of 30 feet, with bracket centers set at 4-foot intervals, ensuring optimal load distribution and support.

Rotation Lock Feature: A rotation lock is integrated into one of the support arms, facilitating controlled movement and enhancing operational safety.

Customizable Drop Length: Customers have the option to specify the drop length of the operating rope, particularly pertinent in manual operations, thereby ensuring tailored functionality to meet specific requirements.

Anchor Trolleys with Auto-Brake Technology: Equipped with two anchor trolleys featuring patented auto-brake technology, this system guarantees smooth and secure movement along the track.

Fixed Stops: To prevent over-travel, fixed stops are installed at both ends of the track, serving as fail-safes to ensure operational safety.

High Thrust/Pull Loading Capacity: With a ±4400-pound thrust/pull loading capacity, this system offers robust performance and reliability for demanding operational environments.

Optimized Weight: Weighing approximately 1128 pounds, this system strikes a balance between structural integrity and maneuverability, facilitating ease of installation and operation.

Durable Coating: Coated with yellow industrial enamel specifically formulated for indoor applications, this system offers enhanced corrosion resistance and maintains a professional aesthetic.

Comprehensive System: The system is delivered as a complete package, inclusive of swing arms, track, trolleys, end stops, splice(s) (if required), and hangers, ensuring seamless integration and operational readiness.

Fold-Away Anchor TrackTM System Standard
Worker Capacity: 2 -User (Non-Passable) Trussed Single Track
Includes (2) Support Arms
Arm Reach: 6-0"
Track Length: 33-0" Including 18" Overhangs on Both Ends
Support Centers 30-0"
Bracket Centers 4'-0"
Rotation Lock on One Arm Included
*Customer Must Specify Drop Length of Operating Rope - ONLY IF MANUAL,
REMOVE IF MOTORIZED*
**Designed to be used ONLY when fully extended**
Trolleys: 2 Anchor Trolley(s) with Patented Auto-Brake
Technology
Fixed Stops Two at Each End
Thrust/Pull Loading: ± 4400
Weight: ± 1128 lbs
Coating & Painting: Yellow Industrial Enamel for Indoor Application
The system is complete with swing arms, track, trolley(s), end stops, splice(s) (if
applicable), and hangers.
