Standard Fold-Away Anchor TrackTM System 1-User (Non-Passable) Trussed Single Track, includes (2) Support Arms, Arm Reach: 6'-0", Bracket Centers 4'-0", Thrust/Pull Loading: ± 3300, Weight: 855 lbs FAF-1-06-23-520-20 Rigid Lifelines

Product Overview

• Worker Capacity: Engineered for a single user capacity, this Fold-Away Anchor TrackTM System ensures non-passable functionality, prioritizing user safety in industrial environments.

• Trussed Single Track Design: Featuring a trussed single track, this system provides robust support while minimizing weight. The trussed design enhances structural integrity, ensuring reliability and stability during operation.

• Support Arms Inclusion: The system includes two support arms to provide additional stability and support during use. These support arms contribute to the overall safety and functionality of the system.

• Impressive Arm Reach: With an arm reach extending up to 6 feet, this system enables users to access distant points within the workspace with precision and efficiency, enhancing productivity.

• Extended Track Length: The track measures 23 feet in length, including 18-inch overhangs on both ends, providing ample coverage within the workspace. The extended track length ensures versatility and flexibility in various industrial applications.

• Optimal Support Centers: Supported by brackets spaced 20 feet apart, this system ensures optimal support and stability during operation. The strategic placement of support centers enhances structural integrity and reliability.

• Bracket Centers: Brackets are spaced 4 feet apart along the track, ensuring even weight distribution and structural stability. The well-designed bracket placement contributes to the overall performance and safety of the system.

• Rotation Lock Feature: One of the support arms includes a rotation lock, providing additional safety and stability during use. The rotation lock prevents unintended rotation of the arm, ensuring controlled movement and enhancing user confidence.

• Custom Drop Length of Operating Rope: Customers are required to specify the drop length of the operating rope, particularly relevant for manual operation. This customization ensures proper installation and operation of the system, aligning with individual application requirements.

• Exclusive Auto-Brake Technology: Equipped with an anchor trolley featuring patented auto-brake technology, this system ensures smooth and controlled movement along the track. The auto-brake function engages automatically, enhancing safety and preventing unintended traversal.

• Fixed Stops: Fixed stops are integrated at each end of the track to prevent the trolley from traversing beyond the designated limits. These fixed stops serve as safety features, ensuring controlled operation within the predefined range and minimizing the risk of accidents or damage.

• High Loading Capacity: Capable of withstanding thrust or pull loading of up to ±3300 pounds, this system demonstrates exceptional strength and durability. Its robust construction ensures reliable performance in demanding industrial environments.

• Optimized Weight: Weighing approximately 1201 pounds, this system strikes a balance between structural stability and maneuverability. The optimized weight facilitates ease of installation and adjustment while providing robust support for overhead movement.

• Durable Coating and Painting: Coated with yellow industrial enamel specifically formulated for indoor applications, this system offers superior corrosion resistance and durability. The durable coating ensures long-term protection against environmental factors, maintaining a professional appearance in indoor work environments.

• Comprehensive System Inclusions: The system comes complete with swing arms, track, trolley(s), end stops, and any necessary splices and hangers. This comprehensive inclusion ensures ease of installation and operation, streamlining the setup process.

Fold-Away Anchor TrackTM System Standard
Worker Capacity: 1-User (Non-Passable) Trussed Single Track
Includes (2) Support Arms
Arm Reach: 6'-0"
Track Length: 23'-0" Including 18" Overhangs on Both Ends
Support Centers 20'-0"
Bracket Centers 4'-0"
Rotation Lock on One Arm Included
*Customer Must Specify Drop Length of Operating Rope - ONLY IF MANUAL,
REMOVE IF MOTORIZED*
**Designed to be used ONLY when fully extended**
Trolleys: 1 Anchor Trolley(s) with Patented Auto-Brake
Technology
Fixed Stops One at Each End
Thrust/Pull Loading: ± 3300
Weight: ± 1201 lbs
Coating & Painting: Yellow Industrial Enamel for Indoor Application
The system is complete with swing arms, track, trolley(s), end stops, splice(s) (if
applicable), and hangers.
