Product Overview
Duct-O-Wire RC-P1M1 Industrial Remote Control System
Compact Power. Rugged Performance.
The Duct-O-Wire RC-P1M1 from the RC Pocket Series redefines convenience in industrial control. Engineered for portability and built to endure, this transmitter fits in the palm of your hand without compromising reliability or performance. Ideal for light-duty, mobile, and industrial machinery, the RC-P1M1 offers streamlined control with maximum efficiency.
Key Features
- Ultra-Compact Design – Among the smallest transmitters on the market
- Durable & Industrial-Grade – Shock-resistant, high-vibration tolerant
- Lightweight – Approximately 1/3 lb., including batteries
- Advanced Security – Over 4.1 billion unique ID codes
- Energy Efficient – Up to 3 months of operation on 2 AA batteries
- Extended Range – Operates up to 300+ feet
- Broad Temperature Tolerance – -49°F to +176°F
- Onsite Maintenance Ready – Remote ID setting capability
- Smart Alerts – Low power LED indicator and button jam detection
General Specifications
- Enclosure: IP65, fiberglass/ABS
- Operating Temperature: -49°F to +176°F
- Relay Rating: 10A @ 250VAC, 15A @ 32VDC (consult factory for DC config)
- ID Code: 32-bit (4.1+ billion unique codes)
- Range: Up to 300+ feet
- Regulatory: FCC Part 15 (Unlicensed Operation)
Transmitter Specs
- Dimensions: 4.72" L x 2.17" W x 1.00" H
- Weight: ~1/3 lb (with batteries)
- Power Supply: 2 AA alkaline batteries
- Output Power: ≤ 4mW
- Current Draw: ≈ 10mA
- Indicators: Red LED for low battery, jammed button detection
- Build: Integrated shock resistance
Receiver Specs
- Dimensions: 6.34" L x 2.91" W x 2.05" H
- Weight: 2.43 lbs
- Power Input: AC: 110V / DC: 12–24V
- Sensitivity: Near -105 dBm
- Mounting: Shock-resistant feet
