Detroit Hoist Under Running Double Girder Crane, 20 Ton Capacity, 12 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB40U22-12

Write a Review
$45,718.75
$40,003.91
(You save $5,714.84 )
SKU: DB40U22-12
Weight: 1,999.00 LBS
Shipping: $2,163.00 (Fixed Shipping Cost)
Adding to cart… The item has been added
Detroit Hoist Under Running Double Girder Crane, 20 Ton Capacity, 12 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB40U22-12

Detroit Hoist Under Running Double Girder Crane, 20 Ton Capacity, 12 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB40U22-12

$45,718.75
$40,003.91
(You save $5,714.84 )

Detroit Hoist Under Running Double Girder Crane, 20 Ton Capacity, 12 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB40U22-12

$45,718.75
$40,003.91
(You save $5,714.84 )

The UNDER RUNNING DOUBLE GIRDER model DB40U22-12 is a premier solution for heavy-duty industrial applications, engineered to uphold the highest standards of performance and reliability. Designed specifically for environments that require robust lifting capabilities, this crane exemplifies excellence in material handling.

With a remarkable lifting capacity of 20.00 tons, this crane is proficient in managing substantial weights, ensuring effective operation across diverse industrial settings. Its advanced design incorporates a 5-part reeving system that allows for impressive vertical lifts, reaching heights of 22 feet and 4 inches, making it an essential tool for various lifting tasks.

  • Maximum hoist lift speed of 12.00 feet per minute for controlled operation.
  • Equipped with a durable 13.4 kW motor delivering robust lifting power.
  • Closed-loop vector VFD control system for enhanced torque management and optimal safety.
  • Swift trolley movement with a maximum speed of 80.00 feet per minute, boosting operational efficiency.
  • Four 0.3 kW motors driving the trolley, ensuring balanced movement even with heavy loads.
  • Easy compatibility with a standard 230VAC-3PH-60HZ power supply for industrial use.
  • CMAA Class specifications tailored for indoor services in atmosphere class D environments.
  • Trolley gauge measuring 96.0000 inches for sufficient load clearance.
  • Approximately 3800.00 lbs, offering robust construction and optimal weight distribution.
  • Comprehensive mechanical drawing available for precise installation.

The DB40U22-12 model is not just about power; it combines innovative engineering features with user-friendly operation. Its UL508A c UL us listed industrial control panel ensures safety and reliability under rigorous conditions. This crane sets the industry standard, providing the precision and durability needed for heavy industrial operations. Experience the difference with the UNDER RUNNING DOUBLE GIRDER crane, where innovation meets performance for all your material handling needs.

The Company warrants the equipment against defects in material and workmanship for one (1) year from the date of shipment, provided operation is maintained within Class D service conditions, and will replace free of charge, F.O.B. its manufacturing plant, any part (other than wire rope or rope guide rings) found defective, provided the purchaser immediately informs the Company of the defect and no repairs or alterations have been performed by the purchaser or a third party without the Company's written approval; this warranty excludes normal wear and parts inherently subject to premature wear, and the Company is not responsible for phase reversal on the connected power station network, nor liable for damages caused by improper installation or use, lifting loads above rated capacity, or consequential damages, claims, expenditures, or losses arising from operational delays or work stoppages caused by defective equipment. All repairs during the warranty period must be authorized by the Company, and the warranty applies only if the purchaser provides a signed Equipment Certification Form certifying that the equipment has been properly installed, tested, and is in satisfactory working order; the warranty excludes damage caused by improper storage, installation, unauthorized repairs, misuse, improper wiring or electrical service, improper handling, overloading, unsuitable fuels or oils, improper modifications or maintenance, faulty construction or foundations, unsuitable building grounds, chemical/electro-chemical/electrical influences, or other circumstances beyond the Company's fault, and all warranties become null and void if the purchaser or any subsequent user engages in such improper conduct or if such circumstances occur, in which case the Company is free of all obligations, costs, and liabilities under the warranty. All warranties extend only to the purchaser in privity of contract with the Company, and the purchaser - not the Company - is solely responsible for informing equipment users of all warranty and liability limitations; except as stated, no express, implied, or statutory warranty is made by the Company, and the Company is free of any warranty obligations should the purchaser default on agreed payment terms.
