Detroit Hoist Under Running Double Girder Crane, 11 Ton Capacity, 13 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB22U29-13

Write a Review
$47,000.00
$41,125.00
(You save $5,875.00 )
SKU: DB22U29-13
Weight: 1,999.00 LBS
Shipping: $1,480.00 (Fixed Shipping Cost)
Adding to cart… The item has been added
Detroit Hoist Under Running Double Girder Crane, 11 Ton Capacity, 13 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB22U29-13

Detroit Hoist Under Running Double Girder Crane, 11 Ton Capacity, 13 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB22U29-13

$47,000.00
$41,125.00
(You save $5,875.00 )

Detroit Hoist Under Running Double Girder Crane, 11 Ton Capacity, 13 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB22U29-13

$47,000.00
$41,125.00
(You save $5,875.00 )

The UNDER RUNNING DOUBLE GIRDER Model DB22U29-13 is a powerhouse in material handling, boasting a remarkable capacity of 11.00 tons. Designed for efficiency and reliability, this crane is ideal for demanding industrial applications that require precise load handling.

With superior engineering, the Model DB22U29-13 integrates advanced features that enhance productivity and safety. The crane is equipped with a 4-part reeving system that allows for a lift height of 29 feet and 1 inch, assuring optimal lifting performance even under heavy loads. Experience outstanding control and efficiency, making it the ideal choice for your material handling needs.

  • Load Capacity: 11.00 tons, ensuring robustness for industrial lifting.
  • Hoist Lift Speed: A maximum speed of 13.00 FPM provides controlled and efficient vertical handling.
  • Hoist Motor: Powered by a 7.5 kW motor for reliable lifting performance.
  • Hoist Control: Features advanced closed-loop vector VFD for precise load handling and operational safety.
  • Trolley Speed: An impressive maximum speed of 80.00 FPM facilitates quick horizontal movement.
  • Trolley Motor: Four high-efficiency motors rated at 0.3 kW ensure smooth trolley operation.
  • Trolley Control: Sensorless vector VFD control for responsive and accurate trolley movements.
  • Power Supply: Compatible with standard 230VAC, 3-phase, 60Hz systems.
  • CMAA Compliance: Meets industry standards for safety, designed for indoor service in atmosphere class D conditions.
  • Trolley Gauge: A gauge of 96 inches ensures stability during movement.
  • Durable Construction: Approximately 2600 lbs, built with robust materials for longevity.
  • Advanced Features: Includes dynamic braking, motor overload protection, and adjustable electronic encoder limits for enhanced safety and precision.

Invest in the UNDER RUNNING DOUBLE GIRDER Model DB22U29-13 for unparalleled lifting capabilities in your industrial operations. With its sophisticated design and robust functionalities, expect nothing less than efficiency and reliability in every lifting task. Elevate your operations with a crane that is built to perform and engineered for excellence.

The Company warrants the equipment against defects in material and workmanship for one (1) year from the date of shipment, provided operation is maintained within Class D service conditions, and will replace free of charge, F.O.B. its manufacturing plant, any part (other than wire rope or rope guide rings) found defective, provided the purchaser immediately informs the Company of the defect and no repairs or alterations have been performed by the purchaser or a third party without the Company's written approval; this warranty excludes normal wear and parts inherently subject to premature wear, and the Company is not responsible for phase reversal on the connected power station network, nor liable for damages caused by improper installation or use, lifting loads above rated capacity, or consequential damages, claims, expenditures, or losses arising from operational delays or work stoppages caused by defective equipment. All repairs during the warranty period must be authorized by the Company, and the warranty applies only if the purchaser provides a signed Equipment Certification Form certifying that the equipment has been properly installed, tested, and is in satisfactory working order; the warranty excludes damage caused by improper storage, installation, unauthorized repairs, misuse, improper wiring or electrical service, improper handling, overloading, unsuitable fuels or oils, improper modifications or maintenance, faulty construction or foundations, unsuitable building grounds, chemical/electro-chemical/electrical influences, or other circumstances beyond the Company's fault, and all warranties become null and void if the purchaser or any subsequent user engages in such improper conduct or if such circumstances occur, in which case the Company is free of all obligations, costs, and liabilities under the warranty. All warranties extend only to the purchaser in privity of contract with the Company, and the purchaser - not the Company - is solely responsible for informing equipment users of all warranty and liability limitations; except as stated, no express, implied, or statutory warranty is made by the Company, and the Company is free of any warranty obligations should the purchaser default on agreed payment terms.
