Detroit Hoist Under Running Double Girder Crane, 16.5 Ton Capacity, 13 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB33U29-13

Write a Review
$40,820.31
$35,717.78
(You save $5,102.53 )
SKU: DB33U29-13
Weight: 1,999.00 LBS
Shipping: $1,935.00 (Fixed Shipping Cost)
Adding to cart… The item has been added
Detroit Hoist Under Running Double Girder Crane, 16.5 Ton Capacity, 13 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB33U29-13

Detroit Hoist Under Running Double Girder Crane, 16.5 Ton Capacity, 13 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB33U29-13

$40,820.31
$35,717.78
(You save $5,102.53 )

Detroit Hoist Under Running Double Girder Crane, 16.5 Ton Capacity, 13 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB33U29-13

$40,820.31
$35,717.78
(You save $5,102.53 )

The UNDER RUNNING DOUBLE GIRDER crane, Model DB33U29-13, is engineered for high efficiency and exceptional performance in industrial applications. Boasting a substantial capacity of 16.50 tons, this powerful crane is the ultimate solution for handling heavy loads with ease and precision.

Designed with functionality in mind, this crane features an impressive lift height of 29 feet and 1 inch, facilitated by a sophisticated 4-part reeving system that ensures efficient lifting. The hoisting speed is calibrated to a maximum of 13.00 feet per minute, enabling quick and safe load handling, making it indispensable for busy operational environments.

  • Capacity: 16.50 tons, perfect for a variety of heavy lifting tasks.
  • Hoist Lift Speed: Up to 13.00 feet per minute for efficient load handling.
  • Hoist Motor: Robust 10.4 kW motor delivers powerful lifting ability.
  • Hoist Control: Advanced closed-loop vector Variable Frequency Drive (VFD) for precise control.
  • Trolley Speed: Maximum speed of 80.00 feet per minute ensures quick transport of loads.
  • Trolley Motor: Four 0.3 kW motors provide reliable and efficient maneuvering.
  • Trolley Control: Sensorless vector VFD control enhances operational smoothness.
  • Power Supply: Compatible with standard electric supply, 230VAC-3PH-60HZ.
  • CMAA Class: Catered for indoor service in atmospheric class D conditions.
  • Trolley Gauge: Spanning 96 inches, designed for optimal maneuverability.
  • Weight: Approximately 3400 lbs, ensuring stability and durability in operation.

Choose the UNDER RUNNING DOUBLE GIRDER crane for its superior functionality, user-friendly controls, and robust construction. Elevate your operational capabilities and tackle your lifting challenges with confidence, knowing that this crane is built to perform under demanding conditions.

The Company warrants the equipment against defects in material and workmanship for one (1) year from the date of shipment, provided operation is maintained within Class D service conditions, and will replace free of charge, F.O.B. its manufacturing plant, any part (other than wire rope or rope guide rings) found defective, provided the purchaser immediately informs the Company of the defect and no repairs or alterations have been performed by the purchaser or a third party without the Company's written approval; this warranty excludes normal wear and parts inherently subject to premature wear, and the Company is not responsible for phase reversal on the connected power station network, nor liable for damages caused by improper installation or use, lifting loads above rated capacity, or consequential damages, claims, expenditures, or losses arising from operational delays or work stoppages caused by defective equipment. All repairs during the warranty period must be authorized by the Company, and the warranty applies only if the purchaser provides a signed Equipment Certification Form certifying that the equipment has been properly installed, tested, and is in satisfactory working order; the warranty excludes damage caused by improper storage, installation, unauthorized repairs, misuse, improper wiring or electrical service, improper handling, overloading, unsuitable fuels or oils, improper modifications or maintenance, faulty construction or foundations, unsuitable building grounds, chemical/electro-chemical/electrical influences, or other circumstances beyond the Company's fault, and all warranties become null and void if the purchaser or any subsequent user engages in such improper conduct or if such circumstances occur, in which case the Company is free of all obligations, costs, and liabilities under the warranty. All warranties extend only to the purchaser in privity of contract with the Company, and the purchaser - not the Company - is solely responsible for informing equipment users of all warranty and liability limitations; except as stated, no express, implied, or statutory warranty is made by the Company, and the Company is free of any warranty obligations should the purchaser default on agreed payment terms.
