Description

The DB33U38-13 UNDER RUNNING DOUBLE GIRDER crane, with a substantial capacity of 16.50 tons, is the quintessential solution for industries that require precision and reliability in heavy load handling. Engineered with meticulous attention to detail, this crane is designed to enhance operational efficiency while ensuring maximum safety in various industrial applications.

This cutting-edge crane features a 4-part reeving system that offers a lifting height of 38 feet, making it perfect for diverse lifting tasks where vertical reach is paramount. The hoist lift speed of 13.00 feet per minute facilitates smooth and controlled operations, significantly boosting productivity during material handling processes.

  • Heavy-duty construction with a capacity of 16.50 tons for optimal load management.
  • 4-part reeving system to achieve a 38-foot lifting height, tailored for extensive vertical lifting needs.
  • Hoist motor rated at 10.4 kW delivers robust lifting power, guaranteeing consistent performance.
  • Closed-loop vector VFD control for precision in speed regulation and torque management.
  • Maximum trolley speed of 80.00 feet per minute ensures swift and efficient load transport.
  • Four 0.3 kW trolley motors provide seamless movement across the crane span.
  • Sensorless vector VFD control enhances trolley maneuverability and positioning accuracy.
  • Compatible with a 230VAC-3PH-60HZ power supply, making it suitable for standard industrial power systems.
  • Engineered to meet CMAA Class specifications, ideal for indoor environments with atmosphere class D conditions.
  • Trolley gauge of 108.0000 inches offers ample clearance for efficient material handling.
  • Weighs approximately 3400.00 lbs, balancing stability and durability for long-term operation.
  • Features premium-grade graphite ductile iron wheels and sheaves for enhanced durability and longevity.
  • Equipped with a UL508A c UL us listed industrial control panel ensuring top-tier control and safety standards.
  • Over-weight protection and precise load management due to the advanced frequency drive technology.

The DB33U38-13 crane is not only a powerhouse of efficiency and reliability but also incorporates advanced safety features that ensure safe operation in demanding work environments. Its sophisticated technology provides exceptional dynamic braking and overload protection, further solidifying its status as a leader in the heavy lifting domain. Experience the ultimate in industrial lifting solutions with the DB33U38-13 UNDER RUNNING DOUBLE GIRDER crane, setting new standards in performance and safety.

Warranty Information
The Company warrants the equipment against defects in material and workmanship for one (1) year from the date of shipment, provided operation is maintained within Class D service conditions, and will replace free of charge, F.O.B. its manufacturing plant, any part (other than wire rope or rope guide rings) found defective, provided the purchaser immediately informs the Company of the defect and no repairs or alterations have been performed by the purchaser or a third party without the Company's written approval; this warranty excludes normal wear and parts inherently subject to premature wear, and the Company is not responsible for phase reversal on the connected power station network, nor liable for damages caused by improper installation or use, lifting loads above rated capacity, or consequential damages, claims, expenditures, or losses arising from operational delays or work stoppages caused by defective equipment. All repairs during the warranty period must be authorized by the Company, and the warranty applies only if the purchaser provides a signed Equipment Certification Form certifying that the equipment has been properly installed, tested, and is in satisfactory working order; the warranty excludes damage caused by improper storage, installation, unauthorized repairs, misuse, improper wiring or electrical service, improper handling, overloading, unsuitable fuels or oils, improper modifications or maintenance, faulty construction or foundations, unsuitable building grounds, chemical/electro-chemical/electrical influences, or other circumstances beyond the Company's fault, and all warranties become null and void if the purchaser or any subsequent user engages in such improper conduct or if such circumstances occur, in which case the Company is free of all obligations, costs, and liabilities under the warranty. All warranties extend only to the purchaser in privity of contract with the Company, and the purchaser - not the Company - is solely responsible for informing equipment users of all warranty and liability limitations; except as stated, no express, implied, or statutory warranty is made by the Company, and the Company is free of any warranty obligations should the purchaser default on agreed payment terms.
