Detroit Hoist Under Running Double Girder Crane, 20 Ton Capacity, 12 FPM Lift Speed, 80 FPM Trolley Speed, 108" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB40U29-12
DB40U29 -12
video
Detroit Hoist Under Running Double Girder Crane, 20 Ton Capacity, 12 FPM Lift Speed, 80 FPM Trolley Speed, 108" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB40U29-12
DB40U29 -12

  • Guaranteed Fitment

    Always the correct part

  • In-House Experts

    We know our products

  • Added Value

    FREE in house engineering and design assistance

  • Wordwide Delivery

    Free shipping on all Harrington orders over 500LBS

Detroit Hoist Under Running Double Girder Crane, 20 Ton Capacity, 12 FPM Lift Speed, 80 FPM Trolley Speed, 108" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB40U29-12

Write a Review
$46,535.16
$40,718.26
(You save $5,816.90 )
SKU: DB40U29-12
Weight: 1,999.00 LBS
Shipping: $2,277.00 (Fixed Shipping Cost)
Adding to cart… The item has been added
Detroit Hoist Under Running Double Girder Crane, 20 Ton Capacity, 12 FPM Lift Speed, 80 FPM Trolley Speed, 108" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB40U29-12

Detroit Hoist Under Running Double Girder Crane, 20 Ton Capacity, 12 FPM Lift Speed, 80 FPM Trolley Speed, 108" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB40U29-12

$46,535.16
$40,718.26
(You save $5,816.90 )

Detroit Hoist Under Running Double Girder Crane, 20 Ton Capacity, 12 FPM Lift Speed, 80 FPM Trolley Speed, 108" Trolley Gauge, 230V 3PH 60Hz, VFD Controls, Model DB40U29-12

$46,535.16
$40,718.26
(You save $5,816.90 )
Description

The DB40U29-12 Under Running Double Girder crane is designed for heavy-duty industrial applications, offering unparalleled performance in material handling solutions. With a powerful capacity of 20.00 tons, this crane is engineered to meet the rigorous demands of today's industrial environments, ensuring optimal efficiency and reliability.

This advanced crane system features a robust 5-part reeving mechanism that provides an impressive lifting height of 29 feet and 5 inches. The controlled hoist lift speed of 12.00 feet per minute guarantees precision during material handling, while enhancing workplace safety. Coupled with a formidable 13.4 kW motor, the hoist operates consistently, providing steady lifting capabilities even under substantial loads.

  • Hoist Control: Equipped with advanced closed-loop vector Variable Frequency Drive (VFD) technology for precise speed and torque management.
  • Trolley Performance: Achieves a swift maximum speed of 80.00 feet per minute, facilitating quick load movements across the crane span.
  • Trolley Control: Features a highly efficient sensorless vector VFD control system allowing for smooth, accurate load positioning.
  • Standard Power Supply: Operates seamlessly on a 230VAC, 3-phase, 60Hz power supply, compatible with most industrial setups.
  • Durability: Designed to comply with CMAA Class specifications for indoor use, ensuring robust performance in atmosphere class D conditions.
  • Trolley Gauge: With a generous gauge of 108.0000 inches, ample clearance is provided for efficient load movement without obstructions.
  • Model Weight: Approximately 4000.00 lbs, delivering stability and dependability during operation.
  • Premium Components: Features four inverter-rated motors, along with high-quality ductile iron wheels and sheaves for enhanced durability.
  • Dynamic Braking System: Includes functionalities for dynamic braking and motor overload protection through sophisticated frequency drives.
  • High Performance Hoist Operation: The hoist includes a closed-loop flux vector drive, 100% dynamic braking, and precise control without motor brake fatigue.

Engineered for precision, efficiency, and reliability, the DB40U29-12 Under Running Double Girder crane is the ideal choice for businesses aiming to streamline their material handling processes. Trust in the unmatched performance and safety features of this crane to elevate your industrial operations.

Warranty Information
The Company warrants the equipment against defects in material and workmanship for one (1) year from the date of shipment, provided operation is maintained within Class D service conditions, and will replace free of charge, F.O.B. its manufacturing plant, any part (other than wire rope or rope guide rings) found defective, provided the purchaser immediately informs the Company of the defect and no repairs or alterations have been performed by the purchaser or a third party without the Company's written approval; this warranty excludes normal wear and parts inherently subject to premature wear, and the Company is not responsible for phase reversal on the connected power station network, nor liable for damages caused by improper installation or use, lifting loads above rated capacity, or consequential damages, claims, expenditures, or losses arising from operational delays or work stoppages caused by defective equipment. All repairs during the warranty period must be authorized by the Company, and the warranty applies only if the purchaser provides a signed Equipment Certification Form certifying that the equipment has been properly installed, tested, and is in satisfactory working order; the warranty excludes damage caused by improper storage, installation, unauthorized repairs, misuse, improper wiring or electrical service, improper handling, overloading, unsuitable fuels or oils, improper modifications or maintenance, faulty construction or foundations, unsuitable building grounds, chemical/electro-chemical/electrical influences, or other circumstances beyond the Company's fault, and all warranties become null and void if the purchaser or any subsequent user engages in such improper conduct or if such circumstances occur, in which case the Company is free of all obligations, costs, and liabilities under the warranty. All warranties extend only to the purchaser in privity of contract with the Company, and the purchaser - not the Company - is solely responsible for informing equipment users of all warranty and liability limitations; except as stated, no express, implied, or statutory warranty is made by the Company, and the Company is free of any warranty obligations should the purchaser default on agreed payment terms.
