Detroit Hoist Top Running Double Girder Crane (Low Profile), 20 Ton Capacity, 12 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, Model DB40LH22-12

Write a Review
$38,000.00
$33,250.00
(You save $4,750.00 )
SKU: DB40LH22-12
Weight: 2,400.00 LBS
Shipping: Calculated at Checkout
Capacity: 40,000 - 49,999 lbs
Lift: 22.3 ft
Mounting: Top Running
Configuration: Double Girder
Voltage: 230/3/60
Adding to cart… The item has been added
Detroit Hoist Top Running Double Girder Crane (Low Profile), 20 Ton Capacity, 12 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, Model DB40LH22-12

Detroit Hoist Top Running Double Girder Crane (Low Profile), 20 Ton Capacity, 12 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, Model DB40LH22-12

$38,000.00
$33,250.00
(You save $4,750.00 )

Detroit Hoist Top Running Double Girder Crane (Low Profile), 20 Ton Capacity, 12 FPM Lift Speed, 80 FPM Trolley Speed, 96" Trolley Gauge, Model DB40LH22-12

$38,000.00
$33,250.00
(You save $4,750.00 )

Optimize your material handling operations with the Top Running Double Girder Low Profile crane, designed meticulously for robust performance and exceptional versatility.

With a lifting capacity of 20.00 tons, this crane is ideally suited for even the most demanding industrial applications. Its advanced engineering incorporates a top-running double girder low-profile suspension, ensuring a stable and secure platform ideal for heavy lifting operations, while its low profile design maximizes vertical lifting space.

  • Robust Capacity: Lifts up to 20.00 tons, accommodating heavy industrial loads with ease.
  • Versatile Reeving: Five-part line reeving offers a vertical lift of 22'­4" for flexibility across various heights.
  • Efficient Hoist Speed: Achieves a maximum lift speed of 12.00 feet per minute for quick, efficient vertical movements.
  • Powerful Motor: Equipped with a 13.4 kW motor that ensures reliable performance in heavy-duty applications.
  • Intelligent Control: Closed-loop vector Variable Frequency Drive (VFD) for smooth, precise operation and enhanced safety.
  • Fast Trolley Speed: Capable of moving loads at a maximum trolley speed of 80.00 FPM for swift horizontal transport.
  • Durable Trolley Motor: Features dual 0.86 kW motors for consistent movement and reliable load positioning.
  • Adaptive Trolley Control: Sensorless vector VFD control provides responsive maneuvering capability.
  • Reliable Power Supply: Operates on standard electric power, rated at 230VAC, 3-phase, 60Hz, ensuring compatibility across various environments.
  • CMAA Class D Rating: Designed to withstand outdoor conditions, ensuring longevity and durability.
  • Roomy Trolley Gauge: A spacious trolley gauge of 96.0000 inches permits smooth operation and exceptional stability.

This crane is classified for standard weather-resistant use, making it a versatile addition to any industrial setting. Elevate your productivity and safety with features like dynamic braking, overload protection, electronic encoder limit settings, and options for control voltage adjustments. Invest in the Top Running Double Girder Low Profile crane and experience superior lifting performance, innovative technology, and peace of mind in your operational requirements.

The Company warrants the equipment against defects in material and workmanship for one (1) year from the date of shipment, provided operation is maintained within Class D service conditions, and will replace free of charge, F.O.B. its manufacturing plant, any part (other than wire rope or rope guide rings) found defective, provided the purchaser immediately informs the Company of the defect and no repairs or alterations have been performed by the purchaser or a third party without the Company's written approval; this warranty excludes normal wear and parts inherently subject to premature wear, and the Company is not responsible for phase reversal on the connected power station network, nor liable for damages caused by improper installation or use, lifting loads above rated capacity, or consequential damages, claims, expenditures, or losses arising from operational delays or work stoppages caused by defective equipment. All repairs during the warranty period must be authorized by the Company, and the warranty applies only if the purchaser provides a signed Equipment Certification Form certifying that the equipment has been properly installed, tested, and is in satisfactory working order; the warranty excludes damage caused by improper storage, installation, unauthorized repairs, misuse, improper wiring or electrical service, improper handling, overloading, unsuitable fuels or oils, improper modifications or maintenance, faulty construction or foundations, unsuitable building grounds, chemical/electro-chemical/electrical influences, or other circumstances beyond the Company's fault, and all warranties become null and void if the purchaser or any subsequent user engages in such improper conduct or if such circumstances occur, in which case the Company is free of all obligations, costs, and liabilities under the warranty. All warranties extend only to the purchaser in privity of contract with the Company, and the purchaser - not the Company - is solely responsible for informing equipment users of all warranty and liability limitations; except as stated, no express, implied, or statutory warranty is made by the Company, and the Company is free of any warranty obligations should the purchaser default on agreed payment terms.
