Detroit Hoist Top Running Double Girder Crane, 20 Ton Capacity, 5 PD, 29' 5" Lift, 12 FPM Lift Speed, 230V 3PH 60Hz (±5%), Model DB40T29-12

Write a Review
$35,000.00
$30,975.00
(You save $4,025.00 )
SKU: DB40T29-12
Weight: 2,600.00 LBS
Shipping: Calculated at Checkout
Adding to cart… The item has been added
Detroit Hoist Top Running Double Girder Crane, 20 Ton Capacity, 5 PD, 29' 5" Lift, 12 FPM Lift Speed, 230V 3PH 60Hz (±5%), Model DB40T29-12

Detroit Hoist Top Running Double Girder Crane, 20 Ton Capacity, 5 PD, 29' 5" Lift, 12 FPM Lift Speed, 230V 3PH 60Hz (±5%), Model DB40T29-12

$35,000.00
$30,975.00
(You save $4,025.00 )

Detroit Hoist Top Running Double Girder Crane, 20 Ton Capacity, 5 PD, 29' 5" Lift, 12 FPM Lift Speed, 230V 3PH 60Hz (±5%), Model DB40T29-12

$35,000.00
$30,975.00
(You save $4,025.00 )

The Model DB40T29-12 is a top-tier lifting solution designed to meet the demanding needs of industrial environments. With a remarkable capacity of 20.00 tons, this crane offers unmatched lifting power, enabling you to handle large and heavy loads with ease and precision. Engineered for efficiency, the Model DB40T29-12 is the crucial asset your operations require to increase productivity and ensure safety.

Built with a sophisticated 5-part reeving system, this crane facilitates an impressive lift height of 29 feet and 5 inches. By optimizing mechanical advantage, the seamless elevation of hefty loads becomes effortless. With a focus on stability and efficiency, the Model DB40T29-12 delivers controlled and reliable performance throughout your lifting operations.

  • Heavy-duty capacity of 20.00 tons for substantial lifting power.
  • 5-part reeving system providing a lift height of 29' 5" for enhanced vertical elevation.
  • Maximum hoist lift speed of 12.00 FPM for precise movement control.
  • Powerful 13.4 kW hoist motor ensuring smooth load lifting and lowering operations.
  • Advanced closed-loop vector VFD control for superior hoisting performance.
  • Maximum trolley speed of 60.00 FPM for swift horizontal load movement.
  • Two high-performance trolley motors rated at 0.86 kW each for reliable propulsion.
  • Sensorless vector VFD control for responsive and efficient trolley movements.
  • Compatible with standard electrical systems at 230VAC, 3-phase, and 60Hz (+5%).
  • Compliant with CMAA Class D standards, suitable for various atmospheric conditions.
  • Durable trolley gauge of 78.0000 inches enhancing stability during operation.
  • Constructed with robust materials, weighing approximately 2600.00 lbs, ensuring durability.
  • Equipped with premium-grade components including ductile iron wheels and sheaves for long-lasting performance.

The Model DB40T29-12 is not just a crane; it is a powerful lifting partner designed for operational excellence in industrial settings. With a robust build quality and advanced technology features, it guarantees optimal safety and performance, making it a valuable addition to your equipment lineup.

The Company warrants the equipment against defects in material and workmanship for one (1) year from the date of shipment, provided operation is maintained within Class D service conditions, and will replace free of charge, F.O.B. its manufacturing plant, any part (other than wire rope or rope guide rings) found defective, provided the purchaser immediately informs the Company of the defect and no repairs or alterations have been performed by the purchaser or a third party without the Company's written approval; this warranty excludes normal wear and parts inherently subject to premature wear, and the Company is not responsible for phase reversal on the connected power station network, nor liable for damages caused by improper installation or use, lifting loads above rated capacity, or consequential damages, claims, expenditures, or losses arising from operational delays or work stoppages caused by defective equipment. All repairs during the warranty period must be authorized by the Company, and the warranty applies only if the purchaser provides a signed Equipment Certification Form certifying that the equipment has been properly installed, tested, and is in satisfactory working order; the warranty excludes damage caused by improper storage, installation, unauthorized repairs, misuse, improper wiring or electrical service, improper handling, overloading, unsuitable fuels or oils, improper modifications or maintenance, faulty construction or foundations, unsuitable building grounds, chemical/electro-chemical/electrical influences, or other circumstances beyond the Company's fault, and all warranties become null and void if the purchaser or any subsequent user engages in such improper conduct or if such circumstances occur, in which case the Company is free of all obligations, costs, and liabilities under the warranty. All warranties extend only to the purchaser in privity of contract with the Company, and the purchaser - not the Company - is solely responsible for informing equipment users of all warranty and liability limitations; except as stated, no express, implied, or statutory warranty is made by the Company, and the Company is free of any warranty obligations should the purchaser default on agreed payment terms.
