Detroit Hoist Top Running Double Girder Crane, 20 Ton Capacity, 5 PD, 22' 4" Lift, 12 FPM Lift Speed, 230V 3PH 60Hz (±5%), Model DB40T22-12

Write a Review
$34,000.00
$30,100.00
(You save $3,900.00 )
SKU: DB40T22-12
Weight: 2,400.00 LBS
Shipping: Calculated at Checkout
Adding to cart… The item has been added
Detroit Hoist Top Running Double Girder Crane, 20 Ton Capacity, 5 PD, 22' 4" Lift, 12 FPM Lift Speed, 230V 3PH 60Hz (±5%), Model DB40T22-12

Detroit Hoist Top Running Double Girder Crane, 20 Ton Capacity, 5 PD, 22' 4" Lift, 12 FPM Lift Speed, 230V 3PH 60Hz (±5%), Model DB40T22-12

$34,000.00
$30,100.00
(You save $3,900.00 )

Detroit Hoist Top Running Double Girder Crane, 20 Ton Capacity, 5 PD, 22' 4" Lift, 12 FPM Lift Speed, 230V 3PH 60Hz (±5%), Model DB40T22-12

$34,000.00
$30,100.00
(You save $3,900.00 )

The DB40T22-12 heavy-duty crane is engineered for peak performance in industrial environments, offering an impressive capacity of 20.00 tons. This top-running double girder suspension crane is designed to handle significant lifting tasks while maintaining safety and efficiency. With its robust construction and advanced features, this crane is the optimal choice for businesses seeking reliable lifting solutions.

This crane boasts a maximum lift height of 22 feet and 4 inches, made possible by a 5-part reeving system that enhances operational versatility. Its design ensures exceptional lifting capabilities, allowing for quick elevation of heavy materials while maintaining stability and precision. The DB40T22-12 is not just built for strength; it's built for speed, with a hoist lift speed of up to 12.00 feet per minute, enabling efficient operations and minimized downtime.

  • Maximum lifting capacity of 20.00 tons for handling heavy loads
  • 5-part reeving system for enhanced mechanical advantage
  • Hoist lift speed of 12.00 feet per minute for efficient operations
  • Powered by a 13.4 kW hoist motor for reliable performance
  • Closed-loop vector Variable Frequency Drive (VFD) control for precise lifting
  • Maximum trolley speed of 60.00 feet per minute for swift horizontal movement
  • Two trolley motors rated at 0.86 kW each for efficient propulsion
  • Sensorless vector VFD control for smooth and accurate trolley movement
  • Compatible with standard electrical systems operating at 230VAC, 3-phase
  • Weather-resistant design suitable for atmosphere class D applications
  • Trolley gauge of 66.0000 inches providing stability during operations
  • Sturdy construction weighing approximately 2400.00 lbs for enhanced durability

With features including rubber bumpers, advanced braking systems, and a UL508A-listed industrial control panel, the DB40T22-12 is designed for the safety and reliability needed in demanding environments. Its premium components, such as graphite ductile iron wheels and sheaves, ensure longevity and performance. Invest in the DB40T22-12 crane for a lifting solution that enhances operational productivity and safety in your facility.

The Company warrants the equipment against defects in material and workmanship for one (1) year from the date of shipment, provided operation is maintained within Class D service conditions, and will replace free of charge, F.O.B. its manufacturing plant, any part (other than wire rope or rope guide rings) found defective, provided the purchaser immediately informs the Company of the defect and no repairs or alterations have been performed by the purchaser or a third party without the Company's written approval; this warranty excludes normal wear and parts inherently subject to premature wear, and the Company is not responsible for phase reversal on the connected power station network, nor liable for damages caused by improper installation or use, lifting loads above rated capacity, or consequential damages, claims, expenditures, or losses arising from operational delays or work stoppages caused by defective equipment. All repairs during the warranty period must be authorized by the Company, and the warranty applies only if the purchaser provides a signed Equipment Certification Form certifying that the equipment has been properly installed, tested, and is in satisfactory working order; the warranty excludes damage caused by improper storage, installation, unauthorized repairs, misuse, improper wiring or electrical service, improper handling, overloading, unsuitable fuels or oils, improper modifications or maintenance, faulty construction or foundations, unsuitable building grounds, chemical/electro-chemical/electrical influences, or other circumstances beyond the Company's fault, and all warranties become null and void if the purchaser or any subsequent user engages in such improper conduct or if such circumstances occur, in which case the Company is free of all obligations, costs, and liabilities under the warranty. All warranties extend only to the purchaser in privity of contract with the Company, and the purchaser - not the Company - is solely responsible for informing equipment users of all warranty and liability limitations; except as stated, no express, implied, or statutory warranty is made by the Company, and the Company is free of any warranty obligations should the purchaser default on agreed payment terms.
