Product Overview
Bishamon ESX-21 – Heavy-Duty Electric Scissor Lift Table
High Capacity. Superior Control. Built for Industrial Demands.
The Bishamon ESX-21 is a high-performance electric-hydraulic scissor lift table engineered for safe, ergonomic lifting of heavy loads up to 2,100 lbs. Designed for industrial and warehouse environments, the ESX-21 delivers smooth, efficient vertical motion, reducing worker fatigue and increasing productivity at workstations, conveyor lines, packaging areas, and more.
Built with rugged all-steel construction and a powerful electric hydraulic pump, this model offers precise height adjustment at the push of a button. The low-profile platform simplifies loading and unloading, while the integrated safety features—including a velocity fuse, maintenance locks, and pressure relief valve—ensure secure, reliable operation in even the most demanding settings.
Key Features
- 460 lb Capacity – Lifts heavy loads with ease for manufacturing, assembly, and logistics
- Electric Hydraulic System – Delivers powerful, consistent lifting at the touch of a button
- Heavy-Duty Steel Frame – Built for durability and continuous use in industrial settings
- Large, Stable Platform – Supports a wide variety of load sizes and shapes
- Low Profile Design – Makes loading and unloading more ergonomic
- Safety-First Engineering – Includes velocity fuse, pressure relief valve, and mechanical maintenance locks
- Powder-Coated Finish – Resists wear, corrosion, and impact in harsh environments
- Simple Plug-in Operation – No air supply required—just connect to power and go
Benefits
- Improves Ergonomic Safety – Keeps materials at an ideal working height
- Reduces Manual Lifting – Minimizes strain, fatigue, and risk of injury
- Enhances Throughput – Speeds up loading/unloading and assembly operations
- Versatile Applications – Suitable for factories, packaging stations, and shipping areas
- Maintenance-Friendly – Designed for long life with minimal upkeep
Technical Specifications – Bishamon ESX-21
SpecificationDetails
Model ESX-21
Capacity 460 lbs (208.65 kg)
Platform Size 24" x 48" (custom options available)
Lowered Height 6.5 inches
Raised Height 36.5 inches
Lift Type Electric Hydraulic
Power Requirement 115V, 1-phase (standard)
Controls Push-button pendant or foot control
Lift Time (approx.) 30–35 seconds
Construction Heavy-duty welded steel
Finish Industrial-grade powder coat
Safety Features Velocity fuse, maintenance lock bar, pressure relief valve
Weight Approx. 400 lbs
Applications Industrial lifting, assembly lines, pallet handling, workstation elevation
