Product Overview
Bishamon ESX-40 – Heavy-Duty Electric Scissor Lift Table
Maximum Strength. Industrial Grade. Built to Lift Big.
The Bishamon ESX-40 is a high-capacity electric-hydraulic scissor lift table designed for demanding industrial applications where loads up to 800lbs need to be safely and efficiently raised, lowered, and positioned. With its rugged all-steel construction and powerful electric-hydraulic system, the ESX-40 provides smooth, reliable operation in manufacturing plants, assembly lines, warehouse facilities, and maintenance shops.
This lift table offers an optimal combination of strength, safety, and ergonomic design. Workers can easily raise or lower materials to the correct height, reducing strain and boosting productivity. The low-profile platform makes loading simple, while a suite of safety features—including a velocity fuse and mechanical maintenance locks—provides peace of mind in any industrial setting.
Key Features
- 4,000 lb Capacity – Handles heavy, bulky loads with ease
- Electric Hydraulic Operation – Consistent, quiet lift performance with push-button control
- Low-Profile Platform – Eases loading/unloading without the need for ramps
- Heavy-Duty Steel Construction – Ensures longevity in harsh working environments
- Durable Powder-Coated Finish – Resists chips, corrosion, and wear
- Advanced Safety Systems – Includes a velocity fuse, maintenance locks, and pressure relief valve
- Simple Plug-and-Play Setup – Runs on standard power; no air or hydraulic infrastructure needed
Benefits
- Reduces Strain and Fatigue – Lifts loads to a safe, ergonomic working height
- Improves Workflow Efficiency – Minimizes handling time and maximizes output
- Ideal for Heavy-Duty Applications – Supports production, shipping, and assembly operations
- Safe and Reliable – Built with multiple redundancies and safety mechanisms
- Easy to Operate and Maintain – Minimal training required; low maintenance
Technical Specifications – Bishamon ESX-40
SpecificationDetails
Model ESX-40
Capacity 800 lbs (363 kg)
Platform Size 24" x 48" (other sizes available)
Lowered Height 6.5 inches
Raised Height 36.5 inches
Lift Type Electric-hydraulic
Power Requirement 115V, 1-phase
Control Options : Foot pedal or push-button pendant
Lift Speed Approx. 30–40 seconds full stroke
Construction Heavy-duty welded steel
Finish Blue powder-coated industrial finish
Safety Features Velocity fuse, maintenance lock, pressure relief valve
Weight Approx. 280 lbs
Applications Heavy-duty lifting, production lines, pallet positioning, large part assembly
