Product Overview
Atlas Lifting and Rigging ALH-008-10-OP Manual Lever Hoist with Overload Protection
The ALH-008-10-OP is engineered for safe and reliable performance in lifting, pulling, and tensioning applications. With a 0.8-ton (1,600 lbs) capacity and an extended 10-foot lift height, this lever hoist features integrated mechanical overload protection, adding a critical safety layer by preventing operation beyond the rated load.
Its robust steel construction, paired with a heat-treated alloy steel load chain, ensures durability in challenging job site conditions. The ergonomic lever design enables precise load control and forged swivel hooks with safety latches provide secure and flexible rigging. This hoist is ideal for users requiring a balance of extended reach, durability, and safety assurance.
Key Features:
- 0.8-Ton Capacity with Overload Protection: Built-in slip clutch protects against overloading.
- 10-Foot Lift Height: Extra reach for varied lifting or pulling tasks.
- Durable Steel Frame: Resists wear in industrial environments.
- Heat-Treated Alloy Steel Load Chain: Offers high strength and corrosion resistance.
- Ergonomic Lever Handle: Designed for operator comfort and control.
- Quick Reversal Lever: Allows smooth switching between lifting and lowering.
- Forged Steel Swivel Hooks with Safety Latches: Enable safe, 360° load attachment.
Specifications:
- Model: ALH-008-10-OP
- Capacity: 0.8 Ton (1,600 lbs / 725 kg)
- Lift Height: 10 ft (3 m)
- Overload Protection: Integrated mechanical slip clutch
- Load Chain: Heat-treated alloy steel
- Lever Handle Length: Approx. 14 inches
- Hook Type: Forged steel swivel hooks with safety latches
- Operating Temperature: -40°F to 140°F (-40°C to 60°C)
- Net Weight: Approx. 18 lbs (8.2 kg)
The Atlas ALH-008-10-OP offers precise handling, and increased safety, making it an excellent choice for light-duty lifting and rigging in maintenance, utility, and industrial settings.
