Atlas Lifting & Rigging HOISTEK HCH-005-15 Hand Chain Hoist

1/2 Ton Capacity | 1,100 lbs | 15 Ft Lift

The Atlas HOISTEK HCH-005-15 Hand Chain Hoist is built for dependable lifting performance, extended reach, and long-term reliability in demanding environments. With a rated load capacity of 1/2 ton (1,100 lbs) and a 15-foot standard lift height, this hoist is ideal for field applications, fabrication shops, equipment maintenance, and overhead lifting in areas without access to power.

Featuring a compact steel frame and precision-machined internal gearing, the HCH-005-15 delivers smooth manual operation with minimal effort. The integrated mechanical load brake ensures positive load control. Holds the load securely at any point during lifting or lowering. An extended lift height of 15 feet offers added versatility for working with elevated structures, machinery, or tall rigging points.

Equipped with a heat-treated Grade 80 alloy steel load chain and forged alloy swivel hooks with safety latches, the hoist provides secure, reliable performance in lifting, pulling, or tensioning applications. It's rugged steel housing and corrosion-resistant finishes ensure continued performance in tough jobsite or shop conditions.

Whether working in confined overhead areas or expansive industrial settings, the HCH-005-15 combines safety, durability, and manual precision in a lightweight, portable form.

Specifications:

• Model: HCH-005-15
• Brand: Atlas Lifting & Rigging HOISTEK
• Rated Capacity: 1/2 Ton (1,100 lbs)
• Standard Lift Height: 15 Feet
• Hand Chain Pull to Lift Full Load: Approx. 40–45 lbs
• Load Chain: Grade 80 alloy steel, black oxide coated
• Hand Chain: Zinc-plated steel
• Brake System: Weston-style mechanical load brake
• Hooks: Forged alloy steel, 360° swivel with heavy-duty safety latches
• Body Construction: Industrial-grade all-steel housing
• Finish: Durable powder coat for corrosion and impact resistance
• Headroom: Compact, low-clearance profile
• Operating Temperature Range: -40°F to 140°F (-40°C to 60°C)
• Net Weight: Approx. 25.5 lbs (11.6 kg)

Strong, versatile, and ready for extended lifting tasks, the Atlas HOISTEK HCH-005-15 offers the manual control and rugged performance professionals depend on when working at height or in variable field conditions.
