Atlas Lifting & Rigging HOISTEK HCH-005-20 Hand Chain Hoist

1/2 Ton Capacity | 1,100 lbs | 20 Ft Lift

The Atlas HOISTEK HCH-005-20 Hand Chain Hoist is engineered for maximum reach and dependable lifting performance in environments where strength, control, and durability are critical. Hoist has a lifting capacity of 1/2 ton (1,100 lbs) and an extended 20-foot lift height, this hoist is ideal for applications such as tall structure assembly, high-bay maintenance, overhead rigging, and remote jobsite operations.

Designed for reliability and long-term use, the HCH-005-20 features a rugged all-steel body with precision-machined gears for smooth operation and reduced operator fatigue. The hoist’s mechanical load brake delivers secure and accurate load control, allowing safe lifting and lowering at any height. A free-chain mechanism enables quick and simple hook positioning, improving workflow in fast-paced environments.

The hoist is equipped with a heat-treated Grade 80 alloy steel load chain and forged swivel hooks with heavy-duty safety latches, ensuring secure and stable load handling. Its weather-resistant powder-coated finish and corrosion-resistant components make it well-suited for both indoor and outdoor jobsite conditions.

With its extended lift height and compact, low-headroom design, the HCH-005-20 combines portability with the performance needed to handle lifting tasks at greater elevations safely.

Specifications:

• Model: HCH-005-20
• Brand: Atlas Lifting & Rigging HOISTEK
• Rated Capacity: 1/2 Ton (1,100 lbs)
• Standard Lift Height: 20 Feet
• Hand Chain Pull to Lift Full Load: Approx. 40–45 lbs
• Load Chain: Grade 80 alloy steel, black oxide finish
• Hand Chain: Zinc-plated steel for smooth operation
• Brake System: Mechanical load brake (Weston-style)
• Hooks: Forged alloy steel, 360° swivel with locking safety latches
• Body Construction: All-steel housing with reinforced structure
• Finish: Industrial powder-coated exterior for corrosion and wear resistance
• Headroom: Compact, low-profile for tight spaces
• Operating Temperature Range: -40°F to 140°F (-40°C to 60°C)
• Net Weight: Approx. 28.5 lbs (12.9 kg)

Reliable, efficient, and built for elevated lifting, the Atlas HOISTEK HCH-005-20 is the go-to manual hoist for professionals who require extra reach without compromising safety or control.
