Atlas Lifting & Rigging Compact 1/2 Ton Manual Chain Hoist – 20 Ft. Lift

Product Overview

Atlas Lifting & Rigging ACHC-005-20

Compact 1/2 Ton Manual Chain Hoist – 20 Ft. Lift

The Atlas ACHC-005-20 is a rugged and compact manual chain hoist designed for reliable lifting in overhead and confined space applications. With a 1/2 ton (1,000 lb) lifting capacity and a 20-foot lift height, this model is well-suited for maintenance, rigging, and utility work that demands extra reach without sacrificing mobility or control.

Its robust steel housing, high-strength Grade 80 alloy chain, and precision-machined gearing deliver smooth operation and long-term dependability. A Weston-style mechanical brake ensures safe load holding at any height, making the ACHC-005-20 a trusted choice in both field and industrial environments.

Key Features:

• 1/2 Ton Lifting Capacity: Handles medium-duty loads with safety and control
• 20 Ft. Lift Height: Extended reach ideal for high-lift requirements
• Compact Frame: Lightweight and easy to handle in tight or elevated locations
• Grade 80 Alloy Load Chain: Heat-treated for maximum strength and resistance to wear
• Mechanical Load Brake: Weston-style brake holds loads securely and reliably
• Swivel Top & Bottom Hooks: Forged steel hooks rotate 360° and include safety latches
• Smooth Gear Operation: Reduces pull force and operator fatigue

Technical Specifications:

SpecificationDetails

Model Number ACHC-005-20

Rated Capacity 1/2 Ton (1,000 lbs)

Lift Height 20 Feet

Load Chain Material Grade 80 Alloy Steel

Load Chain Diameter 5 mm (approx.)

Effort to Lift Full Load ~29–32 lbs

Headroom (hook to hook) Approx. 10–11 inches

Hook Type Forged Steel, Swivel, with Safety Latch

Brake Type Mechanical Weston-Style Load Brake

Net Weight Approx. 24–26 lbs

Compliance ASME B30.16, CE Certified
