Atlas Lifting & Rigging ACHC-005-10

Compact 1/2 Ton Manual Chain Hoist – 10 Ft. Lift

The Atlas ACHC-005-10 is a compact and durable manual chain hoist designed for efficient lifting in low-clearance or tight-access environments. With a 1/2 ton (1,000 lb) capacity and a standard 10-foot lift, this hoist is ideal for maintenance, utility work, rigging, and field service where portability and reliability are essential.

Engineered with a steel body, hardened alloy chain, and a proven mechanical brake system, the ACHC-005-10 offers consistent performance and operator control in demanding conditions—without the bulk of larger hoists.

Features:

• Rated Capacity: 1/2 Ton (1,000 lbs)
• Lift Height: 10 Feet
• Compact Steel Housing: Resists impact and corrosion while keeping the hoist lightweight and easy to handle
• Grade 80 Load Chain: High-strength alloy steel chain offers durability and wear resistance
• Weston-Style Mechanical Load Brake: Secure, automatic braking for controlled lifting and holding
• Forged Swivel Hooks: 360° rotation with safety latches for secure and flexible attachment
• Smooth Gear Operation: Reduces pull effort, improves efficiency, and enhances operator control

Technical Specifications:

SpecificationDetails

Model Number ACHC-005-10

Rated Capacity 1/2 Ton (1,000 lbs)

Lift Height 10 Feet

Load Chain Material Grade 80 Alloy Steel

Load Chain Diameter 5 mm (approx.)

Effort to Lift Full Load ~29–32 lbs

Headroom (hook to hook) Approx. 10–11 inches

Hook Type Forged Steel, Swivel, w/ Safety Latch

Brake Type Mechanical Weston-Style Load Brake

Net Weight Approx. 18–21 lbs

Compliance ASME B30.16, CE Certified
