The OZ010-30CHOP Premium Chain Hoist delivers unmatched performance and safety for heavy-duty lifting and pulling operations. With a 1-ton (2,000 lb) capacity and Standard Overload Protection set at approximately 150% of the rated load, this hoist ensures superior reliability in every lift. The double-reduction gearing system reduces effort while the 360° hand-wheel design provides smooth, easy chain handling from any direction. Built from all-steel construction, it’s engineered for lasting durability and dependable operation in demanding industrial environments.

Product Description

When precision, power, and safety matter most, the OZ010-30CHOP Premium Chain Hoist from OZ Lifting Products delivers the professional-grade performance required in industrial and construction applications. Designed for both lifting and pulling, this hoist features a 1-ton (2,000 lb) rated load capacity and a 30 ft lift height, giving operators the versatility needed to handle a wide range of material handling tasks.

This hoist’s Standard Overload Protection (SOP) automatically activates at approximately 150% of the rated load, preventing accidental overloading and ensuring safer, more controlled lifting. The double-reduction gearing minimizes manual effort, making operation smoother and more efficient, even under heavy loads.

The 360° rotating hand-wheel allows the operator to guide the chain from multiple angles—an essential advantage in confined or tight spaces. The all-steel frame and gear housing provide maximum strength and long-term reliability, while the powder-coated finish resists corrosion and wear for extended service life.

Inside, the Weston-style mechanical brake system with a twin-pawl design guarantees secure load holding, even during extended use. The fully enclosed gearing and sealed roller bearings protect critical components from dust and debris, ensuring smooth, maintenance-free operation.

For added performance, the zinc-plated, heat-treated alloy steel load chain delivers exceptional tensile strength, and the forged alloy hooks—equipped with heavy-duty safety latches—ensure safe, stable load connection. Every OZ hoist meets or exceeds ASME B30.16 and OSHA standards, providing peace of mind that your equipment meets the highest safety benchmarks.

Specifications

• Model: OZ010-30CHOP

• Type: Premium Manual Chain Hoist with Overload Protection

• Capacity: 1 Ton (2,000 lbs)

• Lift Height: 30 ft

• Overload Protection: Factory preset at ~150% of rated load

• Gearing: Double-reduction gearing for smooth, low-effort lifting

• Brake System: Weston-style mechanical brake with twin-pawl design

• Construction: Heavy-duty all-steel frame and housing

• Finish: Powder-coated for corrosion and wear resistance

• Load Chain: Zinc-plated, heat-treated alloy steel chain

• Hooks: Forged alloy steel upper and lower hooks with safety latches

• Bearings: Sealed roller bearings for reduced maintenance

• Gear Enclosure: Fully enclosed to protect against contaminants

• Operation: Manual hand-chain operation for lifting and pulling applications

• Compliance: Meets ASME B30.16 and OSHA requirements

• Applications: Construction, utilities, manufacturing, maintenance, and repair

Key Features

• 1-ton (2,000 lb) capacity and 30 ft lift height for versatile applications

• Standard Overload Protection enhances operator safety

• Double-reduction gearing provides effortless operation

• 360° hand-wheel design allows easy chain control from any direction

• All-steel construction ensures long-lasting durability

• Powder-coated finish protects against corrosion and wear

• Weston-style brake system for dependable load holding

• Zinc-plated alloy load chain for superior strength

• Forged alloy hooks with heavy-duty latches for secure attachment

• Low-maintenance sealed gearing for long-term reliability
