NER Electric Chain Hoist 10' Lift-Capacity 1/4 Tons NER003S Electric Chain Hoist HARRINGTON

Product Overview

The NER003S-10 HARRINGTON NER Electric Chain Hoist is the ultimate solution for handling heavy lifting tasks with ease and efficiency. With a lifting capacity that ranges from 1/8 to 20 tons, this electric hoist is designed to tackle the toughest jobs in the harshest conditions.Featuring a 10-foot lift height, the NER003S-10 provides superior lifting power and versatility for various applications. Whether you're working in construction, manufacturing, or any industry that requires heavy lifting, this electric chain hoist is the ideal choice to elevate your performance.The NER003S-10 is built with cutting-edge technology to ensure smooth and reliable operations. You can trust this electric hoist to deliver peak performance day in and day out, allowing you to work with confidence and get the job done efficiently.Durability is a key feature of the NER003S-10. Constructed with top-quality materials and engineering, this electric chain hoist is built to withstand the rigors of heavy-duty use. It is designed to last, ensuring a long lifespan and minimal downtime.Safety is also a priority with the NER003S-10. It is equipped with advanced safety features to protect both the operator and the load being lifted. With its sturdy construction and reliable performance, this electric hoist provides a safe lifting solution that you can rely on.The NER003S-10 HARRINGTON NER Electric Chain Hoist is a reliable and powerful tool that will exceed your expectations. Invest in this electric hoist and experience the benefits of superior lifting power, durability, and efficiency. Take your performance to new heights with the NER003S-10 and conquer your heavy lifting tasks with ease.

Product Specifications

.

Part Number:

NER003S-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 500 lb, 10 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Quick Disconnect Plugs On Pendant and Power Cords, 10 yr Brake Warranty

Lift Speed:

36 fpm

Housing Width:

12 19/32 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

6 5/8 in

Housing Length:

18 13/16 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

12 19/32 in

Body Depth:

6 5/8 in

For Minimum Beam Height:

Not Applicable

Body Length:

18 13/16 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

10 ft

Controller Cord Length:

8 3/16 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

13 13/16 in

Load Capacity:

500 lb

Minimum Between Hooks:

13 13/16 in

Motor HP:

0.75 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

6 ft

Amps @ Low Volts:

3.4 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted-No Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Dual Speed VFD, Easy Access Suspension, Extreme Duty Motor, Secondary Brake, Smart Brake Technology, State-Of-The-Art Chain Technology, Unique Smart Limit Option

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

36 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/4 hp

Headroom:

13 13/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

3.4 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

1.7 A

Body Finish:

Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
