SNER Electric Chain Hoist 10' Lift-Capacity 1 Tons SNER010S Electric Chain Hoist HARRINGTON

Product Overview

The SNER010S-10 HARRINGTON SNER Electric Chain Hoist is a true powerhouse in the world of lifting equipment. This electric chain hoist is designed specifically for extreme duty applications, making it perfect for heavy-duty lifting tasks. With a lift capacity of 10' and available in Capacity ranging from 1 tons, this hoist has the strength to handle even the toughest jobs.One of the standout features of the SNER010S-10 HARRINGTON SNER Electric Chain Hoist is its single phase power capability. This ensures efficient operation, making your tasks easier and more effective. You can rely on this hoist to get the job done quickly and efficiently, saving you time and effort.Durability is a key factor when it comes to lifting equipment, and the SNER010S-10 HARRINGTON SNER Electric Chain Hoist does not disappoint. It is built to last, with quality materials and a robust construction. You can trust that this hoist will withstand the demands of your toughest jobs and keep performing at its best.When you choose the SNER010S-10 HARRINGTON SNER Electric Chain Hoist, you are choosing a dependable and reliable lifting solution. It is a top-of-the-line hoist that delivers power and precision, giving you the confidence you need to tackle any lifting task. Upgrade your lifting equipment today and experience the difference this hoist can make.Whether you are working in construction, manufacturing, or any industry that requires heavy lifting, the SNER010S-10 HARRINGTON SNER Electric Chain Hoist is a must-have tool. It combines strength, efficiency, and durability to provide you with an exceptional lifting experience. Don't settle for less when it comes to your lifting equipment-choose the SNER010S-10 HARRINGTON SNER Electric Chain Hoist and get the job done right.

Product Specifications

.

Part Number:

SNER010S-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 2,000 lb, 10 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container

Lift Speed:

14 fpm

Housing Width:

13 5/16 in

Manufacturers Warranty Length:

1 yr

Housing Depth:

8 5/16 in

Housing Length:

17 5/16 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 5/16 in

Body Depth:

8 5/16 in

For Minimum Beam Height:

Not Applicable

Body Length:

17 5/16 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 3/16 in

Minimum Retracted Length:

17 5/16 in

Load Capacity:

2,000 lb

Minimum Between Hooks:

17 5/16 in

Motor HP:

1.2 hp

Phase:

1

Standards:

ASME B30.16, ASME HST-1, NFPA 70

Voltage:

115/230V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

No

Control Cord:

6 ft

Amps @ Low Volts:

23.9 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

14 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 1/4 hp

Headroom:

17 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

2,000 lb

Current at Minimum Voltage:

23.9 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

0

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
