Product Overview
The SNER010S-20 HARRINGTON SNER Electric Chain Hoist is the ultimate solution for heavy-duty applications. With its single-phase capability, this electric chain hoist delivers reliable power that you can depend on. Whether you need to lift 1 tons, this hoist has got you covered with its versatile lifting capacity.With a lift height of 20 feet, this electric chain hoist allows you to easily reach higher areas, making it perfect for a wide range of industrial needs. Whether you are working in a warehouse, factory, or construction site, this hoist will ensure efficiency and performance every time.Built with a robust construction, the SNER010S Electric Chain Hoist is designed to withstand even the toughest working conditions. Its durability and longevity guarantee that it will be able to handle your toughest jobs, day in and day out. No matter how demanding your tasks may be, this hoist will not let you down.Experience the power and reliability of the SNER010S-20 HARRINGTON SNER Electric Chain Hoist today! With its exceptional performance and reliability, you can trust this hoist to get your tasks done with ease and accuracy. Say goodbye to manual labor and let this electric chain hoist do the heavy lifting for you.Invest in the SNER010S-20 HARRINGTON SNER Electric Chain Hoist and take your productivity to new heights. Whether you need to lift heavy equipment, machinery, or materials, this hoist will make your job easier and more efficient. Don't settle for anything less than the best, choose the SNER010S-20 HARRINGTON SNER Electric Chain Hoist for all your lifting needs.Product Specifications
.Product Videos
Videos Hide Videos Show Videos
Custom Field
Part Number SNER010S-20
Color Yellow
Hoist Lift 20 ft
Product Electric Chain Hoist, 2,000 lb, 20 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley
Includes Chain Container
Lift Speed 14 fpm
Housing Width 13 5/16 in
Manufacturers Warranty Length 1 yr
Housing Depth 8 5/16 in
Housing Length 17 5/16 in
For Minimum Beam Flange Width Not Applicable
For Maximum Beam Flange Width Not Applicable
For Maximum Beam Height Not Applicable
MFR Warranty Length 1 yr
Body Width 13 5/16 in
Body Depth 8 5/16 in
For Minimum Beam Height Not Applicable
Body Length 17 5/16 in
Minimum Radius Curve Not Applicable
Maximum Lifting Length 20 ft
Controller Cord Length 16 ft
Trolley Wheel Diameter Not Applicable
Lifting Hook Opening Width 1 3/16 in
Minimum Retracted Length 17 5/16 in
Load Capacity 2,000 lb
Minimum Between Hooks 17 5/16 in
Motor HP 1.2 hp
Phase 1
Standards ASME B30.16, ASME HST-1, NFPA 70
Voltage 115/230V
Fits Brand Harrington Hoists Inc
Lubrication Oil Bath
Reeving 1
Thermal Protection No
Control Cord 16 ft
Amps @ Low Volts 23.9 A
Number of Speeds 1
Trolley Configuration Hook Mounted
Trolley Speed Not Applicable
Features Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake
Lifting Hook Material Carbon Steel
Includes Clutch Clutch Included
Overload Protection Included Yes
Brake Type Pull Rotor
Chain Grade Grade 80
Maximum Lift Speed Not Applicable
Included Components Chain Container, Pendant, Safety Latch Hook
Fixed Lift Speed 14 fpm
Clutch Type Friction Clutch
Minimum Lift Speed Not Applicable
Pendant IP Rating IP65
Chain Finish Nickel Plated
Controls Push Button Pendant=Mount Type=Hook Mounted-No Trolley
Starts and Stops per Hour 360
Duty Classification H4
Maximum Pulling Capacity Not Applicable
Number of Reeves 1
Motor Horsepower 1 1/4 hp
Headroom 17 5/16 in
Includes Brake Brake Included
For Outdoor Use Yes
Hoist IP Rating IP55
Lifting Hook Type Swivel Hook with Safety Latch
Maximum Lifting Capacity 2,000 lb
Current at Minimum Voltage 23.9 A
Trolley Wheel Material Not Applicable
Current at Maximum Voltage 0
Body Finish Enamel
Number of Load Chains 1
Body Material Aluminum
Trolley IP Rating Not Applicable
Programmable Non-Programmable
