Tractel Topal NXR05 40-140 Non-Marring Multiposition Self-Locking Plate Clamp – 1,100 lbs Capacity

The Topal NXR05 40-140 Non-Marring Multiposition Self-Locking Plate Clamp was engineered for lifting and positioning steel plates while protecting surfaces from scratches or damage. Clamp has a working load limit of 1,100 lbs (500 kg) and an adjustable jaw opening range of 1 9/16–5 1/2 inches (40–140 mm), this clamp offers versatility for a wide range of plate thicknesses while maintaining a secure grip.

Featuring an automatic self-locking mechanism, the NXR05 40-140 engages immediately when the load is applied, ensuring stability and safety during vertical or horizontal lifting. Its multiposition design allows rotation up to 180°, providing flexibility for precise material placement in fabrication shops, construction sites, or manufacturing environments.

With a steel body and a cotated surface, this clamp resists wear and corrosion from the elements. This gives you superior performance under demanding everyday conditions. The non-marring cam surface grips firmly without marking the material, making it ideal for finished, coated, or delicate steel plates. Tested to meet and exceed safety standards. The NXR05 40-140 delivers reliable and consistent performance on every lift.

Specifications:

  • Model: NXR05 40-140
  • Working Load Limit: 1,100 lbs (500 kg)
  • Jaw Opening: 1 9/16–5 1/2 in. (40–140 mm) adjustable
  • Weight: 11.2 kg
  • Material: High-strength steel with protective coating
  • Locking Mechanism: Automatic self-locking cam
  • Lifting Orientation: Vertical and horizontal; rotation up to 180°
  • Safety Factor: 3:1 (EN 13155:2003 compliant)
  • Standards Compliance: ANSI B30.20
  • Minimum Load: 5% of WLL (approx. 55 lbs)
  • Maximum Load Surface Hardness: 300 HB
  • Temperature Range: -20°C to +100°C
  • Recommended Use: Lifting and positioning finished, coated, or delicate steel plates

The Topal NXR05 40-140 Non-Marring Multiposition Self-Locking Plate Clamp combines capacity, dependable safety, and surface protection. This makes it the perfect solution for handling a wide variety of steel plate sizes without damaging the material.
