Tractel Topal KT 0.5 0–15 Plate Clamp with Ring – 1,100 lbs (500 kg) Capacity

The Topal KT 0.5 Plate Clamp is a lifting solution designed for handling thin metal plates in industrial, workshop, and fabrication settings. Clamp has a working load limit of 1,100 lbs (500 kg) and an adjustable jaw opening of 0–9/16 in. (0–15 mm), this clamp ensures secure gripping and safe lifting of metal sheets, steel plates, and other flat materials.

Reliable, Safe Lifting

Constructed from high-strength alloy steel, the Topal KT 0.5 Clamp provides dependable performance under repeated lifting operations. The clamp’s jaw is designed to maintain firm contact with the material without slipping, that gives you the safety and confidence during hoisting and moving operations.

Compact and Easy to Use

The clamp’s lightweight and ergonomic design allows for easy attachment and removal from plates. Its integrated lifting ring ensures compatibility with hoists, or cranes, making it useable in a variety of rigging applications. The spring-loaded mechanism automatically adjusts to the plate thickness for a secure hold.

Precision Grip and Control

With a 0–15 mm (0–9/16 in.) opening, the KT 0.5 is ideal for handling thin plates and small sheet metal pieces. The engineered design distributes loads evenly, reducing the risk of material deformation while maintaining safety during lifting.

Specifications

• Model / SKU: Topal KT 0.5 0–15 Plate Clamp with Ring / 189918
• Working Load Limit (WLL): 1,100 lbs (500 kg)
• Jaw Opening: 0–9/16 in (0–15 mm)
• Lifting Type: Vertical lifting with ring attachment
• Material: High-strength alloy steel
• Finish: Industrial corrosion-resistant coating
• Weight: ~2.2 lbs (1 kg)
• Operation: Spring-loaded jaw for secure gripping
• Applications: Single-plate lifting in vertical orientation

Recommended Uses

• Lifting and positioning thin steel plates in fabrication shops
• Handling sheet metal in industrial and manufacturing facilities
• Vertical lifting operations with hoists or cranes
• Applications requiring secure, compact plate clamping

Key Advantages

• Compact and lightweight for easy handling
• Adjustable jaw opening (0–15 mm) for versatility
• High-strength steel construction ensures durability
• Safe, secure grip for thin metal plates
• Compatible with cranes, hoists, and lifting chains via lifting ring
