Tractel Topal NK2-0-30 Multiposition Self-Locking Plate Clamp – 6,600 lbs Capacity

The Topal NK2-0-30 Multiposition Self-Locking Plate Clamp is engineered for professionals who need a safe, and reliable way to lift and position steel plates, beams, and fabricated assemblies. Clamp has a working load limit of 6,600 lbs (3,000 kg) and a jaw opening range of 0–1 1/8 inches (0–30 mm). This clamp provides heavy-duty performance for demanding lifting tasks.

The automatic self-locking mechanism engages as soon as the load is applied, offering consistent clamping pressure and secure handling throughout the lift. Designed for multiposition use, the NK2-0-30 can lift materials vertically, horizontally, or at various angles, and allows controlled rotation up to 180°. This flexibility makes it a great choice for workshops, manufacturing facilities, and construction sites where precision and adaptability matter.

Built with a rugged steel body and a protective hot epoxy coating, the clamp resists corrosion and wear even under tough working conditions. Its serrated cam ensures a firm grip with minimal marking, helping maintain the surface finish of your materials. The NK2-0-30 is built to meet international safety standards, and gives operators confidence in both performance and reliability.

Specifications:

• Model: NK2-0-30
• Working Load Limit (WLL): 6,600 lbs (3,000 kg)
• Jaw Opening: 0–1 1/8 in. (0–30 mm)
• Weight: 10.5 kg
• Material: High-strength steel with hot epoxy coating
• Locking Mechanism: Automatic self-locking cam
• Safety Factor: 3:1 (EN 13155:2003 compliant)
• Standards Compliance: ANSI B30.20
• Temperature Range: -20°C to +100°C
• Minimum Load: 5% of WLL (approx. 330 lbs)
• Maximum Load Surface Hardness: 300 HB
• Lifting Capability: Vertical and horizontal lifting; rotation up to 180°
• Usage Note: Not suitable for fragile or brittle materials

The Topal NK2-0-30 Multiposition Self-Locking Plate Clamp delivers dependable lifting strength, smooth operation, and long-lasting durability — the right choice for professionals who need safe and efficient handling of heavy steel plates.
