Tractel Dynasafe™ HF 05/2 Tension Load Limiting Cell – 2,500 lb Capacity (Model A, Dual Trip Points, No Monitor) - 46188

Write a Review
$2,912.99
SKU: 46188
Weight: 1.00 LBS
Width: 4.30 (in)
Height: 5.22 (in)
Depth: 0.63 (in)
Shipping: Calculated at Checkout
Adding to cart… The item has been added
Tractel Dynasafe™ HF 05/2 Tension Load Limiting Cell – 2,500 lb Capacity (Model A, Dual Trip Points, No Monitor) - 46188

Tractel Dynasafe™ HF 05/2 Tension Load Limiting Cell – 2,500 lb Capacity (Model A, Dual Trip Points, No Monitor) - 46188

$2,912.99
Description

Tractel Dynasafe™ HF 05/2 Tension Load Limiting Cell – 2,500 lb Capacity (Model A, Dual Trip Points, No Monitor) - 46188

Product Description

The Tractel Dynasafe™ HF 05/2 Tension Load Limiting Cell is a reliable overload-protection solution that hass\ been designed to safeguard lifting and tensioning operations. This Model A unit features two independent trip points. This allows for a staged response: a pre-warning at the first threshold and a full stop or alarm at the second. Its built-in micro switches make it fully self-contained, eliminating the need for a separate monitor and simplifying installation.

With a 2,500 lb (1,134 kg) capacity, the HF 05/2 is ideal for medium-duty hoists, winches, cranes, and tensioned wire-rope systems. The device installs directly into the load path, giving you real-time mechanical overload detection to prevent equipment damage, structural stress, and unsafe operating conditions.

Engineered for industrial durability and precise trip activation, the HF 05/2 offers consistent performance in demanding environments. Load cells compact design and dual-trip capability make it a perfect safety solution for operators that need staged load-limiting control.

Specifications

• Capacity: 2,500 lbs (1,134 kg)

• Model: A — 2 trip points

• Switching Device: Two integrated micro switches

• Monitor: Not required (self-contained activation)

• Load Type: Tension

• Activation: Triggers at preset load thresholds for staged overload protection

• Installation: In-line load cell for direct load-path integration

• Typical Applications: Hoists, cranes, winches, overhead lifting systems, tensioned wire ropes, staged overload safety circuits

Warranty Information
Tractel offers various warranties depending on the product, with a general warranty of 24 months on products manufactured by the seller for defects in materials and workmanship. Some specific products, like the tralift™ TT Electric chain hoist, may have a longer 3-year warranty. The warranty typically excludes issues from improper storage, assembly, maintenance, use, or unauthorized modifications and does not cover normal wear or paints.  Key Aspects of a Tractel Warranty:  Duration: The standard warranty period is 24 months (two years) from the date on the order invoice. Coverage: The warranty covers defects in materials and workmanship. Exclusions: The warranty generally does not cover: Improper storage or assembly. Insufficient maintenance or failure to follow operating instructions. Abnormal working conditions. Normal wear and tear. Willful or negligent damage. Modifications or repairs by personnel not certified by Tractel. Paints and coatings. How to Get More Information:  Check Product-Specific Details:  Always refer to the product's documentation or visit the Tractel US website for the exact warranty terms for your specific item. Contact Tractel:  For clarification on a specific warranty or to inquire about a potential claim, contact Tractel directly.
