SNER Electric Chain Hoist Lift-Capacity 3 Tons SNER030C Electric Chain Hoist HARRINGTON

Write a Review
$5,804.17 - $6,484.03
SKU: SNER030C-10
Condition: New
Weight: 207.00 LBS
Shipping: Free Shipping
Color: Yellow
Hoist Lift: 10, 15, 20
Product: Electric Chain Hoist, 6,000 lb, Hook Mounted-No Trolley, Yellow Hoist Mount Hook Mounted-No Trolley
Includes: Chain Container
Lift Speed: 3.5 fpm
Housing Width: 13 3/16 in
Manufacturers Warranty Length: 1 yr
Housing Depth: 8 5/16 in
Housing Length: 29 1/2 in
For Minimum Beam Flange Width: Not Applicable
For Maximum Beam Flange Width: Not Applicable
For Maximum Beam Height: Not Applicable
MFR Warranty Length: 1 yr
Body Width: 13 3/16 in
Body Depth: 8 5/16 in
For Minimum Beam Height: Not Applicable
Body Length: 29 1/2 in
Minimum Radius Curve: Not Applicable
Maximum Lifting Length: 20 ft
Controller Cord Length: 6 ft
Trolley Wheel Diameter: Not Applicable
Lifting Hook Opening Width: 1 11/16 in
Minimum Retracted Length: 26 29/32 in
Load Capacity: 6,000 lb
Minimum Between Hooks: 29 1/2 in
Motor HP: 1.2 hp
Phase: 1
Standards: ASME B30.16, ASME HST-1, NFPA 70
Voltage: 115/230V
Fits Brand: Harrington Hoists Inc
Lubrication: Oil Bath
Reeving: 2
Thermal Protection: No
Control Cord: 6 ft
Amps @ Low Volts: 23.9 A
Number of Speeds: 1
Trolley Configuration: Hook Mounted
Trolley Speed: Not Applicable
Features: Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake
Lifting Hook Material: Carbon Steel
Includes Clutch: Clutch Included
Overload Protection Included: Yes
Brake Type: Pull Rotor
Chain Grade: Grade 80
Maximum Lift Speed: Not Applicable
Included Components: Chain Container, Pendant, Safety Latch Hook
Fixed Lift Speed: 3.5 fpm
Clutch Type: Friction Clutch
Minimum Lift Speed: Not Applicable
Pendant IP Rating: IP65
Chain Finish: Nickel Plated
Controls: Push Button Pendant=Mount Type=Hook Mounted-No Trolley
Starts and Stops per Hour: 360
Duty Classification: H4
Maximum Pulling Capacity: Not Applicable
Number of Reeves: 2
Motor Horsepower: 1 1/4 hp
Headroom: 29 1/2 in
Includes Brake: Brake Included
For Outdoor Use: Yes
Hoist IP Rating: IP55
Lifting Hook Type: Swivel Hook with Safety Latch
Maximum Lifting Capacity: 6,000 lb
Current at Minimum Voltage: 23.9 A
Trolley Wheel Material: Not Applicable
Current at Maximum Voltage: 0
Body Finish: Enamel
Number of Load Chains: 1
Body Material: Aluminum
Trolley IP Rating: Not Applicable
Programmable: Non-Programmable
Adding to cart… The item has been added
SNER Electric Chain Hoist Lift-Capacity 3 Tons SNER030C Electric Chain Hoist HARRINGTON

SNER Electric Chain Hoist Lift-Capacity 3 Tons SNER030C Electric Chain Hoist HARRINGTON

$5,804.17 - $6,484.03

SNER Electric Chain Hoist Lift-Capacity 3 Tons SNER030C Electric Chain Hoist HARRINGTON

$5,804.17 - $6,484.03

The SNER030C HARRINGTON SNER Electric Chain Hoist is a heavy-duty lifting solution that exceeds expectations. With a capacity of 3 tons, this hoist can effortlessly handle extreme loads in a wide range of industrial applications.What sets the SNER030C-10 HARRINGTON SNER Electric Chain Hoist apart is its compatibility with single-phase power. This versatility allows for easy lifting,lowering, and positioning of heavy objects in various industrial settings.Safety is paramount, and this hoist is designed with advanced safety mechanisms to ensure efficient and accident-free lifting operations. Providing exceptional performance while prioritizing worker well-being, the SNER030C HARRINGTON SNER Electric Chain Hoist can be trusted for all your lifting needs.Durability is a key feature of this hoist, as it is built to withstand the toughest conditions. The robust construction ensures that it can handle heavy usage without compromising reliability, making it a sound investment for your business.The SNER030C-10 HARRINGTON SNER Electric Chain Hoist incorporates cutting-edge technology that delivers the power and precision required for heavy-duty lifting. This innovative hoist is a step above the rest, ensuring your operations benefit from the latest advancements.Choose the SNER030C HARRINGTON SNER Electric Chain Hoist if you need a reliable and powerful solution for your heavy-duty applications. Its exceptional performance,durability, and innovative features make it the perfect lifting solution for any industrial setting.Invest in the power and precision of the SNER030C HARRINGTON SNER Electric Chain Hoist today. Experience the difference it can make in your lifting operations and have confidence in its ability to handle your heavy-duty needs. Don't settle for anything less than the best - choose the SNER030C HARRINGTON SNER Electric Chain Hoist.

Buyer must notify HHI in writing within sixty (60) days of discovery of any alleged defect, if within the applicable warranty period. All products sold by HHI are warranted to be free from defects in material and workmanship from date of shipment by HHI for the following periods: 1 year – Electric and Air Powered Hoists (excluding (N)ER2 Hoists and EQ/SEQ Hoists), Powered Trolleys, Powered Tiger Track Jibs and Gantries, Crane Components, Below the Hook Devices, Spare / Replacement Parts 2 years – Manual Hoists & Trolleys, Beam Clamps 3 years – (N)ER2 Hoists, EQ/SEQ Hoists, (T)EM/(T)SEM hoists, and RY Hoists 5 years – Manual Tiger Track Jibs and Gantries, Hoist Motor Brakes for EQ/SEQ, (T)EM/(T)SEM, and RY 10 years – (N)ER2 Brake, TNER Hoist Motor Brake The product must be used in accordance with manufacturer’s recommendations and must not have been subject to abuse, lack of maintenance, misuse, negligence, or unauthorized repairs or alterations. Should any defect in material or workmanship occur during the above time period in any product, as determined by HHI’s inspection of the product, HHI agrees, at its discretion, either to replace (not including installation) or repair the part or product free of charge. For customers in the U.S., delivery shall be made F.O.B. HHI’s place of business. For international customers, delivery shall be made FCA HHI place of business, United States of America (Incoterms 2010). No warranty claim will be honored without a valid proof of purchase. Customer must obtain a Return Goods Authorization as directed by HHI or its published repair center prior to shipping product for warranty evaluation. An explanation of the complaint must accompany the product. Product must be returned freight prepaid. Upon repair, the product will be covered for the remainder of the original warranty period. Replacement parts installed after the original warranty period will only be eligible for replacement (not including installation) for a period of one year from the installation date. If it is determined there is no defect, or that the defect resulted from causes not within the scope of HHI’s warranty, the customer will be responsible for the costs of returning the product. HHI DISCLAIMS ANY AND ALL OTHER WARRANTIES OF ANY KIND, EXPRESSED OR IMPLIED, AS TO THE PRODUCT’S MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. HHI WILL NOT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY OR FOR INCIDENTAL, CONTINGENT, SPECIAL OR CONSEQUENTIAL DAMAGES, LOSS OR EXPENSE ARISING IN CONNECTION WITH THE USE OR MISUSE OF THE PRODUCTS, REGARDLESS OF WHETHER THE DAMAGE, LOSS OR EXPENSE RESULTS FROM ANY ACT OR FAILURE TO ACT BY HHI, WHETHER NEGLIGENT OR WILLFUL, OR FROM ANY OTHER CAUSE.
