SNER Electric Chain Hoist Lift-Capacity 1 Tons SNER010L Electric Chain Hoist HARRINGTON

Write a Review
$3,577.32 - $3,882.85
SKU: SNER010L-10
Condition: New
Availability: In stock
Weight: 121.00 LBS
Width: 21.00 (in)
Height: 29.00 (in)
Depth: 22.00 (in)
Shipping: Free Shipping
Color: Yellow
Hoist Lift: 10, 15, 20
Product: Electric Chain Hoist, 2,000 lb, 10 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley
Includes: Chain Container
Lift Speed: 7 fpm
Housing Width: 10 13/16 in
Manufacturers Warranty Length: 1 yr
Housing Depth: 7 1/2 in
Housing Length: 16 3/32 in
For Minimum Beam Flange Width: Not Applicable
For Maximum Beam Flange Width: Not Applicable
For Maximum Beam Height: Not Applicable
MFR Warranty Length: 1 yr
Body Width: 10 13/16 in
Body Depth: 7 1/2 in
For Minimum Beam Height: Not Applicable
Body Length: 16 3/32 in
Minimum Radius Curve: Not Applicable
Controller Cord Length: 6 ft
Trolley Wheel Diameter: Not Applicable
Lifting Hook Opening Width: 1 3/16 in
Minimum Retracted Length: 16 3/32 in
Load Capacity: 2,000 lb
Minimum Between Hooks: 16 in
Motor HP: 0.6 hp
Phase: 1
Standards: ASME B30.16, ASME HST-1, NFPA 70
Voltage: 115/230V
Fits Brand: Harrington Hoists Inc
Lubrication: Oil Bath
Reeving: 1
Thermal Protection: No
Classification: H4
Control Cord: 6 ft
Amps @ Low Volts: 16.9 A
Number of Speeds: 1
Trolley Configuration: Hook Mounted
Trolley Speed: Not Applicable
Features: Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake
Lifting Hook Material: Carbon Steel
Includes Clutch: Clutch Included
Overload Protection Included: Yes
Brake Type: Pull Rotor
Chain Grade: Grade 80
Maximum Lift Speed: Not Applicable
Included Components: Chain Container, Pendant, Safety Latch Hook
Fixed Lift Speed: 7 fpm
Clutch Type: Friction Clutch
Minimum Lift Speed: Not Applicable
Pendant IP Rating: IP65
Chain Finish: Nickel Plated
Controls: Push Button Pendant=Mount Type=Hook Mounted-No Trolley
Starts and Stops per Hour: 360
Duty Classification: H4
Maximum Pulling Capacity: Not Applicable
Number of Reeves: 1
Motor Horsepower: 5/8 hp
Headroom: 16 in
Includes Brake: Brake Included
For Outdoor Use: Yes
Hoist IP Rating: IP55
Lifting Hook Type: Swivel Hook with Safety Latch
Maximum Lifting Capacity: 2,000 lb
Current at Minimum Voltage: 16.9 A
Trolley Wheel Material: Not Applicable
Current at Maximum Voltage: 8.5 A
Body Finish: Enamel
Number of Load Chains: 1
Body Material: Aluminum
Trolley IP Rating: Not Applicable
Programmable: Non-Programmable
Adding to cart… The item has been added
SNER Electric Chain Hoist Lift-Capacity 1 Tons SNER010L Electric Chain Hoist HARRINGTON

SNER Electric Chain Hoist Lift-Capacity 1 Tons SNER010L Electric Chain Hoist HARRINGTON

$3,577.32 - $3,882.85

SNER Electric Chain Hoist Lift-Capacity 1 Tons SNER010L Electric Chain Hoist HARRINGTON

$3,577.32 - $3,882.85

The SNER010L HARRINGTON SNER Electric Chain Hoist is the ultimate solution for upgrading your lifting operations. With its superior performance and unmatched reliability, this hoist is designed to handle even the most demanding tasks.Operating on a single phase power source, the SNER010L Electric Chain Hoist provides exceptional power and efficiency. Its robust construction ensures long-lasting durability, allowing you to rely on its performance day after day.With a lift capacity ranging from 1 tons, this hoist offers unparalleled versatility. Whether you need to lift heavy machinery or delicate materials, the SNER010L is up to the task. It can tackle a wide range of loads and get the job done with ease.This electric chain hoist is designed with space limitations in mind. Its compact design and 10' lift height make it perfect for industrial environments where space is at a premium. You can trust the SNER010L to maximize productivity and streamline your lifting processes.Harrington is a brand known for its commitment to quality and innovation. When you choose the SNER010L, you can be confident that you're investing in a top-of-the-line product.Upgrade your lifting operations today with the SNER010L HARRINGTON SNER Electric Chain Hoist. Experience the difference in performance and efficiency. Order now and take your lifting capabilities to the next level.

Buyer must notify HHI in writing within sixty (60) days of discovery of any alleged defect, if within the applicable warranty period. All products sold by HHI are warranted to be free from defects in material and workmanship from date of shipment by HHI for the following periods: 1 year – Electric and Air Powered Hoists (excluding (N)ER2 Hoists and EQ/SEQ Hoists), Powered Trolleys, Powered Tiger Track Jibs and Gantries, Crane Components, Below the Hook Devices, Spare / Replacement Parts 2 years – Manual Hoists & Trolleys, Beam Clamps 3 years – (N)ER2 Hoists, EQ/SEQ Hoists, (T)EM/(T)SEM hoists, and RY Hoists 5 years – Manual Tiger Track Jibs and Gantries, Hoist Motor Brakes for EQ/SEQ, (T)EM/(T)SEM, and RY 10 years – (N)ER2 Brake, TNER Hoist Motor Brake The product must be used in accordance with manufacturer’s recommendations and must not have been subject to abuse, lack of maintenance, misuse, negligence, or unauthorized repairs or alterations. Should any defect in material or workmanship occur during the above time period in any product, as determined by HHI’s inspection of the product, HHI agrees, at its discretion, either to replace (not including installation) or repair the part or product free of charge. For customers in the U.S., delivery shall be made F.O.B. HHI’s place of business. For international customers, delivery shall be made FCA HHI place of business, United States of America (Incoterms 2010). No warranty claim will be honored without a valid proof of purchase. Customer must obtain a Return Goods Authorization as directed by HHI or its published repair center prior to shipping product for warranty evaluation. An explanation of the complaint must accompany the product. Product must be returned freight prepaid. Upon repair, the product will be covered for the remainder of the original warranty period. Replacement parts installed after the original warranty period will only be eligible for replacement (not including installation) for a period of one year from the installation date. If it is determined there is no defect, or that the defect resulted from causes not within the scope of HHI’s warranty, the customer will be responsible for the costs of returning the product. HHI DISCLAIMS ANY AND ALL OTHER WARRANTIES OF ANY KIND, EXPRESSED OR IMPLIED, AS TO THE PRODUCT’S MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. HHI WILL NOT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY OR FOR INCIDENTAL, CONTINGENT, SPECIAL OR CONSEQUENTIAL DAMAGES, LOSS OR EXPENSE ARISING IN CONNECTION WITH THE USE OR MISUSE OF THE PRODUCTS, REGARDLESS OF WHETHER THE DAMAGE, LOSS OR EXPENSE RESULTS FROM ANY ACT OR FAILURE TO ACT BY HHI, WHETHER NEGLIGENT OR WILLFUL, OR FROM ANY OTHER CAUSE.
