Product Overview
The DB33M38-16 Monorail System is engineered for exceptional performance and reliability in heavy-duty industrial applications. Designed to address the diverse needs of modern material handling, this cutting-edge hoisting solution maximizes efficiency and operational safety with its robust specifications.
With a remarkable lifting capacity of 16.50 tons, the DB33M38-16 Monorail meets the rigorous demands of heavy material movement. Its versatile installation configurations allow it to adapt seamlessly to various operational environments, making it an ideal choice for warehouses, manufacturing facilities, and other industrial settings.
- Impressive 16.50-ton lifting capacity ensures reliability in material handling tasks.
- Utilizes a 4-part reeving system for a lift height of up to 38 feet, providing significant vertical reach.
- Maximum lift speed of 16.00 feet per minute promotes swift and controlled load movement.
- Powered by a 13.4 kW hoist motor for smooth and reliable lifting performance.
- Closed-loop vector Variable Frequency Drive (VFD) control enhances speed and torque regulation.
- Trolley speed of 80.00 FPM enables efficient horizontal load transportation.
- Equipped with dual 0.55 kW trolley motors for precise lateral movement.
- Sensorless vector VFD control for smooth acceleration and accurate positioning of loads.
- Operates on standard electric power supply (230VAC, 3-phase, 60Hz) for seamless integration.
- Compliant with CMAA Class D standards, ensuring reliability in standard atmospheric conditions.
- Durable construction weighing approximately 2000.00 lbs, maintaining structural integrity during operation.
- Premium grade graphite ductile iron wheels and sheaves provide outstanding durability.
- UL508A listed industrial control panel for added safety and compliance.
- Dynamic braking features for precise control and load protection.
- Adjustable electronic encoder limits for upper and lower range regulation.
The DB33M38-16 Monorail System combines advanced engineering with thoughtful features, making it the ultimate choice for businesses seeking to enhance their operational efficiency and material handling capabilities. Trust in this robust system to deliver reliable performance and unmatched safety in your industrial operations.
