Monorail, Capacity: 16.50 Ton, Hoist Lift Speed: 16.00 FPM Max, Trolley Speed: 80.00 FPM Max, DB33M29-16, Detroit

Suspension / Mount: This model is specifically designed for monorail suspension or mounting configurations, offering versatility in installation to suit various industrial environments and applications.

Capacity: With an impressive lifting capacity of 16.50 tons, the DB33M29-16 is engineered to handle heavy loads reliably, making it suitable for demanding material handling tasks in industrial settings.

Reeving | Lift: Employing a 4-part reeving system, this hoist can achieve a lift height of up to 29 feet and 1 inch, providing substantial vertical reach for lifting and positioning bulky or tall loads with precision.

Hoist Lift Speed: Featuring a maximum lift speed of 16.00 feet per minute (FPM), the hoist system enables efficient vertical movement of loads, contributing to enhanced productivity and operational efficiency in material handling operations.

Hoist Motor: Powered by a robust 13.4 kW hoist motor, the DB33M29-16 delivers ample power and torque to lift heavy loads smoothly and reliably, ensuring consistent performance even under demanding operating conditions.

Hoist Control: Utilizing closed-loop vector Variable Frequency Drive (VFD) control, the hoist system offers precise speed and torque regulation, allowing for accurate positioning and safe handling of loads while minimizing the risk of overloads or jerky movements.

Trolley Speed: With a maximum speed of 80.00 FPM, the trolley system enables swift horizontal movement of loads along the monorail beam, facilitating efficient material handling processes and optimizing overall workflow.

Trolley Motor: Equipped with two 0.55 kW trolley motors, the system provides sufficient power to support smooth and controlled lateral movement of loads, ensuring precise positioning and reliable transportation along the monorail track.

Trolley Control: Featuring sensorless vector VFD control, the trolley system offers smooth acceleration, deceleration, and precise speed control during lateral movement, enhancing operational safety and efficiency in material handling operations.

Power Supply: The hoist system is designed to operate on standard electric power supply at 230VAC, 3-phase, and 60Hz, with a tolerance of ±5%, ensuring compatibility with common industrial power sources and facilitating seamless integration into existing electrical systems.

CMAA Class | Atmosphere | Location: Compliant with CMAA Class D standards, the DB33M29-16 is engineered to operate reliably in standard atmospheric conditions, with weather-resistant features ensuring durability and longevity in challenging environments.

Beam Size: The specific beam size required for installation is outlined in the reference mechanical drawing provided, ensuring precise compatibility and integration with existing infrastructure for seamless installation and operation.

Approximate Weight: Weighing approximately 1900.00 lbs, the DB33M29-16 strikes a balance between robust construction and manageable weight, facilitating ease of installation, handling, and maintenance while ensuring structural integrity and stability during operation.
